Help CenterAutomatic Hydraulic Horizontal CNC Band Saw Machine /horizontal Saw Machine
Related Products
-
GS500 China Jinan SINO Cutting Steel Tool Autormatic CNC Steel Tube Cutting MachineUS$ 12,200 - 12,700MOQ: 1 Set -
GS320 Automatic Hydraulic Horizontal CNC Metal Cut Band /saw Machine Hydraulic MachineryUS$ 6,000 - 7,000MOQ: 1 Set
-
GS400 Round 400mm Automic Band Saw Horizontal CNC Metal Band Saw MachineUS$ 1 - 9,999MOQ: 1 Set
-
CNC Band Saw Machine Metal Cutting Band Saw MachineUS$ 1 - 9,999MOQ: 1 Set
-
CNC Band Saw Machine Metal Cutting Band Saw MachineUS$ 1 - 9,999MOQ: 1 Set
| 1. Cutting feed rate set & controlled by frequency inverter |
| 2. Manually controlled Blade Tension |
| 3. Built-In Coolant System, Vibration flood coolant system to both saw guides |
| 4. Roller stock table |
| 5. Continuous cutting until the material is out of stock on the machine bed |
| 6. Blade cutting speed controlled by speed-adjusting valve on the control pannel. |
Capacity Round |
320mm |
Capacity Rectangular |
320 X 320 mm |
Blade Size (Length/Width/Thickness) |
4115*34*1.1mm |
Control System |
PLC,CNC |
Working theory |
Hydraulic and full automatically |
|
Machine upper frame lifting over material
|
Hydraulically and speed adjustable. |
Sawing speed control method |
Frequency controlled |
Material feeding |
Fully automatic motor-driven roller trolley,no labor required again |
Material Trolley |
Roller table type trolley wither roller,the material will moves along on the rail |
Cutting Length Control |
Controlled by the grating guage |
Power Requirement |
380V,50HZ |
Main Motor Rate |
3.0KW |
Oil Pump motor rate |
0.75KW |
|
Excellent and professional service
| 1.We are a professional manufacturer engaged in the research, development, production, sale |
| and service of band saw machinery. |
Production capacity
Our company have a series of advanced equipment including digital controlledlathe,automatic |
cutting machine and centerless grinding. |
Quality control
The passing rate of finished product is more than 99% . Every product need to be checked by |
by many processes. |
Comprehensive service
We have a good engineer team who can design kinds of products according to customer requirements . |
We have been in this field for 17 years, covering ovearseas market of 30 different countries . |
Band Saw Shipping:
1.By Air or by Sea for batch goods, for FCL; Airport/ Port receiving |
| 2.Customers specifying freight forwarder or negotiable shipping methods! |
| 3.Delivery Time: within 25 days for batch band saw machine. |
Payment Terms
| 1.payment:Payment: T/T, Western Union, MoneyGram |
| 2.30% deposits; 70% balance before delivery. |
| 3. MOQ:one set |
| 4.Warranty : 3 years. |
| 5.Package Information: Plastic film wraped, Steel/plywood box |
1.We are Alibaba Assessed 3 years Gold Supplier. |
| 2.we have trade assurance amount $26000,granted by |
| 3.We are a factory manufacturing led band saw machine, top quality,the most competitive price,Good after – sale service. |
| 4.We have been in this field for 17 years, covering ovearseas market of 30 different countries |
| 5.100% QC inspection Before Shippment. |
