Variable Speed 600mm Cutting Capacity Double Column Horizontal Band Saw Machine for Steel GZ4260
Metal Steel Band Saw Metal Cutting Machinery Work Vice Hydraulic
Advantages and Features:
* Quality made in China
* 2 Rigid & Chrome column for Stable & accurate cutting
* Quick and Easy Blade Speed Change
* Automatic cut cycle, no miter cutting,straight cutting only.
* Automatic step by step material feed
* Hydraulically controlled dual vise clamping system -2 step
* Cutting feed rate set & controlled by frequency inverter
* Bi-Metal Blade for better cutting,low cost and high efficiency
* Heavy duty cast iron gear box
* CE & ISO approved
Detailed Specifications:
Capacity Round |
600mm |
Capacity Rectangular |
600*600mm |
Blade Size (Length/Width/Thickness) |
6300*41*1.3 mm |
Cutting Length Control |
Controlled by the length guage |
Power Requirement |
380V,50Hz or customized |
Main Motor Rate |
5.5KW |
Hydraulic motor rate |
1.5KW |
Coolant Pump rate |
0.09KW |
Blade speed(m/min) |
36/54/72,Inverter |
Vise action Method |
Clamping vise, hydraulic |
Shipping dimensions |
2950*1200*1950MM |
600mm Band Saw Machine for Steel Metal Cutting Machinery Hydraulic power 1.5KW
pipe band saw cutting machine Metal Cutting Machinery Working theory hydraulic
Applications:
The machine can cut the following materials:
Metal Steel Band Saw Metal Cutting Machinery Control semi-automatic
600mm Band Saw Machine for Steel Metal Cutting Machinery Saw blade speed 36*54*72
pipe band saw cutting machine Metal Cutting Machinery Band saw specification 6300*41*1.3
High quality plywood package can give the best protection to bandsaw machine during the long tranpotation.
Metal Steel Band Saw Metal Cutting Machinery Capacity round 600mm
JINAN SINO MACHINE TOOLS CO.,LTD is one professional metal band sawing machine manufacturer from china. We began our business in the year of 1998, and started to export as JINAN SINO TRADE CO.,LTD since 2009.
Now we have 2 brands-NR&JF, and all our products have been CE&ISO certificated. We have the strong capacity in R&D,design and manufacturing.
Our main products include double-column band saw machine, angle band sawing machine, NC band saw machine, vertical band sawing machine , etc. With advanced technology and competitive prices, our products sell well in China as well in the world .
600mm Band Saw Machine for Steel Metal Cutting Machinery Max cutting capacity Round 600mm quadrate 600*600
pipe band saw cutting machine Metal Cutting Machinery Saw blade tension Semi-automic
| Q1: What is your MOQ? |
| A1: Our MOQ is one set. |
| Q2: Can I change the motor voltage and frequency? |
| A2: Yes, voltage and frequency are made as request. |
| Q3: What is your Delivery time? |
| A3: Usually, it's 15 working days after receiving your payment. |
| Q4: Can I use my own logo? |
| A4: Yes, OEM is always be welcome. |
| Q5:What payment method can you accept? |
| A5: T/T, L/C, Escrow |
| Q6: What is your quality guarantee? |
|
A6: Every machine will be strictly inspected and tested before shipping to clients. Besides, we offer 5 years warranty for the band saw machine since the delivery date. |
Metal Steel Band Saw Metal Cutting Machinery
- Two years(24 months) guarantee from the delivery date of band saw machine under the normal and proper operation of one shift per day.
- We'll be responsible for the maintence and repair of the damaged parts during warranty period. The transpotation costs of the damaged replacement parts will be borne by the buyer.
- All the damage caused by man-made mistake or the improper operation is not included.
- Wearing parts( band saw blades) not included.
