Top quality 9hp engine
9hp engine description
1. Engine type: 4 stroke, OHV, air-cooled gasoline engine
2. Runs up to 6 hours on 4 gallon tank.
3. Auto decompressing makes starting easy.
4. OHV design for increased effiency and optional power transfer.
5. Oil alert automatically shut off the engine when oil level is low.
6. Ball bearing supported crankshaft for greater stability.
7. Reduced mechanical noise due to light weight, noise-reducting materials.
8. Recoil start or electric start are optional.
9hp engine parameter
| Model | 90 | 160 | 200 | 210 | 270 | 390 | BS420 |
| Engine type | 154F | 168F | 168-1F | 170F | 177F | 188F | BS190F |
| Bore x Stroke | 154*38mm | 168*45mm | 168*52mm | 170*52mm | 177*58mm | 188*64mm | 190*64mm |
| Displacement | 83cc | 163cc | 196cc | 210cc | 269cc | 389cc | 420cc |
|
Compression ratio |
7.7:1 | 8.5:1 | 8.5:1 | 8.5:1 | 8.2:1 | 8.0:1 | 8.0:1 |
| Max out(HP) | 2.6 | 5.5 | 6.5 | 7.0 | 9.0 | 13 | 15 |
| Max out(KW) | 2.0 | 4.1 | 4.9 | 5.3 | 6.8 | 9.6 | 11.3 |
| Oil Capacity | 0.37L | 0.6L | 0.6L | 0.6L | 1.1L | 1.1L | 1.1L |
| Fuel Capacity | 1.6L | 3.6L | 3.6L | 3.6L | 6.0L | 6.5L | 6.5L |
|
Min,Fuel Consumption ( g-hp/H ) |
450g | 295g | 280g | 280g | 280g | 275g | 275g |
|
Dimensions (LxWxH) |
300x290x280 |
390x330x350 |
510x400x 460 |
510x430x 475 |
510x430x 475 |
||
| Net weight | 10.6kg | 15kg | 16kg | 17kg | 28kg | 33kg | 34kg |
| Ignition system |
non-contact transistorized ignition(TCI) |
||||||
| Starting System |
recoil and hand-operated |
||||||
| Air cleaner | semi-dry,oil bath,dual,double silent and cyclone type | ||||||
| Spark plug | F6RTC | F6RTC | F7RTC | F7RTC | F7RTC | F7RTC | F7RTC |
|
20FT Quantity set |
630 | 630 | 630 | 630 | 268 | 268 | 268 |
|
40HQ Quantity set |
1505 | 1505 | 1505 | 1505 | 652 | 652 | 652 |
9hp engine feature
1. Easy to operate and high safety of petrol engine
2. Precise Machining Technique
3. Long Life of the Machine
4. Delicate and Beautiful Appearance Design
5. Broader Applicable Scope
6. Good quality and less malfunction
9hp engine advantage
1. Portable gasoline generator
2. Economic, low fuel consumption.
3. Compact in structure, low in noise & pollution and high in efficiency.
4. Stable voltage and frequency.
5. Overload protection for safety operation.
6. Exceptional performance at reasonable price.
7. High quality power output
8. Qualified mechanical seal device
9.Compact in structure and convenient for carry
10. Easy starting by both recoil starting and electric starting
11.Special balancer shaft inside reduces the vibration to the minimum level
9hp engine usage
Used in water pump,generator,tiller,boat,go kart,washing machine,tamping machine,air compressor, and so on.widely used in kinds of engineering machine,agriculture machine .
9hp engine picture
Packaging and shipping
Packaging:
1. Plastic Foam
2. Wooden Case
Shipping
1. Plastic for full container load
2. Wooden Case for Less container load
our services
1. Warranty:
Our all products with 1 year warranty.
2. OEM Acceptable:
We accept your brand and customize packing carton available
In follow orders, we can provide spare parts charge lower price.
3. Samples:
Sample is available for checking our quality.
4. Delivery time:
Either sample order or batch order.
