GZ4240 China Hot Sale Double column Hydraulic Band Saw Machine iron saw

FOB Price

USD $3,900 - $4,300 / Set

1 Set(Min.Order)

Port Qingdao port or Tianjin port China
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shandong, China
Brand Name	NR band saw machine	Model Number	GZ4240
Voltage	380V 50HZ	Rated Power	4.0kw
Dimension(LWH)	200012001500mm	Weight	1500kg
Certification	CE & ISO9001	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

China Band Saw Machine iron saw
1.16 years manufacturing experiences
2. CE approved & ISO certificate
3. OEM services

Product Description

GZ4240 China Hot Sale Double column Hydraulic Band Saw Machine iron saw

Main features:

1.With hydraulic system to control the cutting speed ,variable speed

2.Useful guide system ,to keep the blade can be use with long time

3.Double column structure ,steady operations

4.Steady cutting ,high accuracy

5.Hydraulic claming, semi-automatic control,sawing high efficiency

Specific parameters

Capacity Round:	400mm
Capacity Rectangular:	450 X 400 mm
Blade Size (Length/Width/Thickness):	4570×34×1.1 mm
Working theory	Hydraulic and semi-automatically
Material feeding	Manully pull the material
Material Trolley	Portable material trolley with steel strcuture
Cutting Length Control	Controlled by the length guage
Power supply	380V,50Hz
Main Motor Rate	4.0KW
Oil Pump motor rate	0.75KW
Coolant Pump rate	0.09KW
Blade Guide:	Carbide / Roller
Blade speed(m/min):	40/60/80,Inverter
Sawing feed control	Push button to control sawing feed hydraulically
Blade Cleaning	Chip brsuh driven by motor
Blade wheel Driving system:	Belt,Pulley with gear transmission reducer.
Working Light	24V low voltage energy-saving Bulb, safe and longlife.
Maximum Vise Opening:	420 mm
Vise action Method	Hydraulic macro control & manual micro control
Descent Control	Pressure Assist Hydraulic
Return:	Hydraulic
Drive:	Belt/Pulley
Shipping dimensions	2000X1200X1500MM
Shipping Gross Weight	1500KG each set
Packaging	Steel/plywood box suitable for a long-distance inalnd and ocean transportation.
Shipping Schedule	10 working days starting from the receipt of the downpayment

Product Advantages

2 Rigid & Chrome column for Stable & accurate cutting

Quick and Easy Blade Speed Change

Automatic cut cycle, no miter cutting,straight cutting only

Automatic step by step material feed

Hydraulically controlled dual vise clamping system -2 step

Cutting feed rate set & controlled by frequency inverter

Bi-Metal Blade for better cutting,low cost and high efficiecy

Carbide Guides with Roller Backups

Auxiliary lifting cylinders

Manually controlled Blade Tension

Manual control on saw blade up, saw blade down, saw blade action

Built-In Coolant System, Vibration flood coolant system to both saw guides

Product Overviews

Certifications

Company Information

We are the professional metal band sawing machine manufacturer from china.we began our business in the year of 1998.Unitll now we have 2 brands-NR&JF,we have many years experience in manufacturing metal band sawing machine,all our products have been CE&ISO certificated.we have the strong capacity in R&D,Design and manufacturing.our main products include two-column band sawing machine,angle band sawing machine,NC band sawing machine,Vertical band sawing machine and spectral grinding machine,etc.with advanced technology and competitive prices,our products sell well in china as well in the world .

Production Process

Packaging & Shipping

After sales service:
1. 24 hours service on Internet and Telephone, free instructions and problem solving
2. Free training to make sure a master of the operating of cnc router for the person who come to our factory

Finally:

We would like to and ready to do business with any company from all over the world. If you have interests in our products, please don't hesitate to contact with us, we would like to give you the best service any time!
Thanks and best regards!

Michelle
