Automatic cutter double-column metal straight cutting band saw pulleys
- 100 Set / Sets per Month
- Qingdao port; Tianjin port
- T/T L/C D/P D/A
-
1600 Ton Heavy Duty Hydraulic Used Car Shell Gantry Type Shear Machine OEM Available
-
4axis 5axis Large size and thickness(0-40mm) cnc plasma cutting machine
-
Automatic cnc plasma cutting machine gate cnc router 120a/200a
-
Fully automatic 20mm plasma cutting machine custom size high quality
-
200mm pipe table axe for plasma metal cutting machine spare parts in weifang
-
China gantry cnc plasma and oxy cutting machine dust removal equipment
Product Details
| Condition: | New | Place of Origin: | Shandong, China | Brand Name: | nr band saw pulleys |
| Model Number: | GZ4245 | Voltage: | 380V 50HZ | Rated Power: | 4.0kw |
| Dimension(L*W*H): | 2400*1200*1700mm | Weight: | 1600Kg | Certification: | CE ISO |
| Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1.CE approved ISO verified
2.Metal straight cutting
3.Double column for higher stability
4.Semi auto hydraulic control
1. Semi-automatic cut cycle, no miter cutting,straight cutting only
2. Blade Cutting feed rate set & controlled by speed-adjusting valve on the control pannel.
3.Low Voltage/Overload Protection
4. Hydraulically controlled Vise
Product detail
Capacity Round | 450mm |
Capacity Rectangular | 450 450*450mm |
Blade Size (Length/Width/Thickness) | 4930*34*1.1 mm |
Cutting Length Control | Controlled by the length guage |
Power Requirement | 380V,50Hz or customized |
Main Motor Rate | 4.0KW |
Hydraulic motor rate | 0.75KW |
Coolant Pump rate | 0.09KW |
Blade speed(m/min) | 32/48/68,Inverter |
Vise action Method | Clamping vise, hydraulic |
Shipping dimensions | 2400*1200*1700MM |
band saw pulleys Packaging | packing band saw machine 1.Plastic film wraped, 2.Steel/plywood box 3.Suitable for the long distance inland and ocean freight transportation |
Product show
1. Two-column structure,landing and taking off the fuel tank column
2.Semi-automatic control,hydraulic clamping,convenient oper-ation,sawing high efficiency.Two-coclumn structure,landing and landing and taking off the fuel tank column-oriented.
3.Saw a reasonable structure,effectively prolong saw band life
Packaging: Steel/plywood box suitable for the long distance inland and ocean freight transportation
Jinan Sino trade co., LTD is a leading company of specializing in manufacturing and exporting band saw. We are able to offer professional band saw to customers. Our team in China sawing industry especially band sawing machine and band saw blade industry has accumulated rich experience and established a set of technical training machine tool manufacturing, application for the integration of production and research.
Our product have been exported to lots of countries and regions, such as Europe, Russia, Southeast Asia, Middle East, North America, Australia.
