Specifications
CE & ISO Certifiedbundle cutting band saw
Capacity 350mm
High speed & efficiency
Semi auto control
GZ4235 horizontal dual column steel bundle cutting band saw with cutting capcity 350mm
STANDARD FEATURES:
* Quality made in China
* 2 Rigid & Chrome column for Stable & accurate cutting
* Quick and Easy Blade Speed Change
* Automatic cut cycle, no miter cutting,straight cutting only.
* Automatic step by step material feed
* Hydraulically controlled dual vise clamping system -2 step
* Cutting feed rate set & controlled by frequency inverter
* Bi-Metal Blade for better cutting,low cost and high efficiecy
* Heavy duty cast iron gear box designed for band sawing machines, with precision machined worm, phosphorous bronze worm gear, taper roller bearings and oil bath lubrication
* Carbide Guides with Roller Backups
* Auxiliary lifting cylinders
* Manually controlled Blade Tension
* Manual control on saw blade up, saw blade down, saw blade action
* Built-In Coolant System, Vibration flood coolant system to both saw guides
* Blade Powered, Rotary Cleaning Brush
* Servo Motors
* Roller stock table
* Continuous cutting until the material is out of stock on the machine bed
* Blade cutting speed controlled by speed-adjusting valve on the control pannel.
* Blade linear Speed Controlled by Pulley & V-belt
* Low Voltage/Overload Protection
* Work Lights for nighttime or lightless day.
* Safety Guards, Owners Manual
* Hydraulic oil excluded and gear oil included
* Need special features? We can customize these machines
