200W Solar Modules, Poly Crystalline Silicon, High Efficiency

200W Solar Modules, Poly Crystalline Silicon, High Efficiency thumbnail-1
200W Solar Modules, Poly Crystalline Silicon, High Efficiency photo-1
US$ 116 - 130 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BR SOLAR
Model Number:
BR-P200W
Contact Supplier Request Quote Chat Now
Yangzhou Bright Solar Solutions Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI YANGZHOU NANTONG
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name BR SOLAR
Model Number BR-P200W
Material Polycrystalline Silicon
Size 1650*990*50mm
Number of Cells 36
Max. Power 206

Specifications

1.Poly Silicon PV Modules, High Efficiency
2.ISO,CE,RoHS,IEC,FCC,IEC,SONCAP Approved
3.OEM
4.No. 1 Ranking Manufacturer

200W Solar Modules (Model: BR-P200W)
Product Name: 200Watts Solar Panel
Model Number: BR-P200W (6*10=60 Cells)
Standard: TUV, IEC61215, CE & EN
Place of Origin: Jiangsu of China
Solar cell spec: 156*156 Polycrystalline silicon solar cells
Specifications: PV mbdule with 200W maximum power
Max. System voltage: 1000V DC
Power tolerance: 0%-3%
Surface max. Load capacity: 70m/S(200KG/sq. M)
Weight: 20KG
FF(%): 70%



Packaging & Shipping






Detailed Packing:
PV Panel: carton and pallet packing;

Package Photos

200W Solar Modules, Poly Crystalline Silicon, High Efficiency



200W Solar Modules, Poly Crystalline Silicon, High Efficiency



200W Solar Modules, Poly Crystalline Silicon, High Efficiency









Our Services





Our Advantage:

1. Since 1997, we are more than 10 years exporting experience, clients more than 50Courtries;

2. ISO 9001: 2000, TUV, IEC, CE&EN, RoHS, SONCAP CCPIT and CCC approved manufacturer.

3. OEM is available



200W Solar Modules, Poly Crystalline Silicon, High Efficiency



200W Solar Modules, Poly Crystalline Silicon, High Efficiency







Product Description







Specification for 200W Solar Modules
Product Name: 200Watts Solar Panel
Model Number: BR-P200W(36 Cells)
Place of Origin: China
Solar cell spec: 156*156 Poly crystalline silicon solar cells
Specifications: PV module with 206W maximum power
Max. system voltage: 1000V DC
Power tolerance: 0%-3%
Surface max. load capacity: 70m/S(200KG/sq.m)
Weight: 20KG
Dimensions: 1650mm*990mm*50mm
Electrical characteristics:
Vmp(V): 28.81V
Imp(A): 6.94A
Voc(V): 36V
Isc(A): 7.7A
Cell efficiency(%): ≥16.4%
Module efficiency(%): ≥14.4%
FF(%): 70-72%
Conditions (STD):
Bypass Diodes 3pcs 15A
Irradiance: 1000W/M2
Temperature: 25°C
Absolute maximum rating:
Operating temperature: -40°C to +80°C
Storage temperature: -40°C to +80°C
Packing: 2 PCS/CTN
Payment: 30% TT in advance, 70% before shipment or against copy of B/L.
Junction box TUV Certified,MC4 Connector, Water-proof.
Glass High-Transmission,Low iron tempered glass.
Limited Warranty Warranty: 5 years.
90% of minimum power output over 10 years,80% over 25 years.
High reliability with guaranteed +3% power output tolerance,
(Lifespan:20-25 Years)
