High Power Cheapest Electricity 3KW Solar Panel Tracking System

    High Power Cheapest Electricity 3KW Solar Panel Tracking System

solar home lighting system description;

 Solar home kit system this product is high performance,family used portable solar power system ,whitch can receive energy and store it in battery outside

 connected to solar home kit by solar energy on sunny day ,and supplies electric power for varies appliances such as electric fan,lighting lamps, television,portable

computer etc,It can supply power for both DC and AC electric application.

It's very helpful and useful for home electric supply.

solar power lighting system specification:

3000W Off-grid home solar systems (Integrated Type)
Model	BR3000W-250AH
DC Output Voltage(V)	DC24V/5A*3  USB 5.5V/500MA
AC Output Voltage(V)	220V/110V
Solar Panel:2PC	Name	Specification
	Power	250W
	Type	Poly
	VOC	34.6V
	ISC	7.89A
	IMP	7.23A
	VMP	34.6V
Solar Battery:1PC	Name	Specification
	Capacity(AH)	250AH 12V
	Type	Maintenance-free, Deep cycle, Lead Acid Battery
	Installation	Buit-in
Integreated Inverter &Controller:1PC	Name	Specification
	Controller	60A 12V/24V
	Rated Power(W)	3000w
	DC Output Power(V)	DC24V/5A*3  USB 5.5V/500MA
	AC Output Power(V)	220V/110V
	SIZE(mm)	760*260*728
	Protection Function	Overload,Short-circuit Protection
	Shell material	1.0mm cold drawing, spraying plastics
Fittings	Name	Specification
	solar panel	2PC
	LED Lamp	3PC   3W/12V,
	Cable for LED Bulb	3PC
	USB Cable	1PC   10 in 1, All Connection
	Battery box kit	1PC
	REMARK: Maximum charging capacity:2.5Kwh/Day Maximum storage capacity:2.4Kwh/Day Practical loading:2pcs 3W LED lamp,100W computer ,100W color TV set,30W Inkjet 45W fan  100W fridge AC loading using time:6-7 hours DC loading using time:80 hours

 solar lighting system Pictures Show:

Factory supply inverter 3000w solar power lighting systems packaging:

solar power system testing and working well :

 Producing Pictures of Solar Power System:

We are Yangzhou Bright Solar Solutions Co .,Ltd, whose registered address at No.51 Siwangting Road ,Yangzhou City ,Jiangsu Province, China .established in 1997,an ISO 9001:2000,CE&EN, RoHS, Soncap, IEC,TUV,CCPIT,CCC approved Manufacturer and Exporter. We have been successfully selling our solar street lights, LED street lights; solar panels, solar battery, home solar lighting system, solar Courtyard light etc, to overseas markets over 50 countries particularly in Asia, North S/America, W/Africa, etc.

Thanks for reading.If you want to know more detail information or better quatation,please feel free to contract us!
