IP68 20A MPPT Solar Charge Controller

Name: IP68 20A MPPT Solar Charge Controller
Brand: BRSOLAR
SKU: 100875541
Availability: InStock

US$ 15 - 90 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

BRSOLAR

Model Number:

IP68 20A MPPT Solar Charge Controller

Yangzhou Bright Solar Solutions Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI for Alibaba Hot Sale Product solar street light charge controller

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name BRSOLAR

Model Number IP68 20A MPPT Solar Charge Controller

Application Charger Controller

Rated Voltage 12V

Maximum Current 20A

Product Description

IP68 20A MPPT Solar Charge Controller

IP68 20A MPPT Solar Charge Controller Specification

Model	5A	10A	15A	20A
Rated charge current	5A	10A	15A	20A
Rated load current	5A	10A	15A	20A
Working Voltage	12V	12/24V Auto	12/24V Auto	12/24V Auto
Over load, short circuit protection	1.25 rated load current 60sec, 1.5 rated loads current 5sec, over load protection action. ≥3 Rated load current short circuit protection action.
No load current	≤6mA
Charging circuit voltage drop	≤0.26 V
Load circuit voltage drop	≤0.15 V
Over voltage protection	17V; ×2/24V
Work temperature	Industry stage:-35℃ to +55℃
Boost charge voltage	14.6V;×2/24V; (keep 10min)
Direct charge voltage	14.4V; ×2/24V; (keep 10min)
Float charge voltage	13.6V; ×2/24V
charge return voltage	13.2v;×2/24V
Temperature compensation	-5mv/℃/cell (Boost charge, Direct charge, Float charge, charge return voltage)
Lower voltage indicate	12.0V; ×2/24V
Over discharge voltage	11.1V(no load)- real-time modified voltage by the discharge rate;×2/24V
Over discharge return voltage	12.6V; ×2/24V
Control mode	PWM charge mode; modified discharge voltage by the discharge rate
LED indication on system condition	LED indicating the system of charging, overcharge, power full, power low, over-discharge, over load, out short circuit, load on/off, etc.
