P8 SMD 3528 Indoor Lighting LED Module
- 10000 Piece / Pieces per Month
- Zhongshan; Guangzhou
- L/C D/P D/A
Product Details
Model Number: | SM-P8 smd module | Chip Material: | Other, epoxy resin adhesive | Emitting Color: | Other, full color |
Power: | 5W | Power Dissipation: | 7 | ||
Operating Temperature(℃): | -10, 45 | Storage Temperature(℃): | -30, 50 | Place of Origin: | Guangdong, China |
Brand Name: | SkyMax Display | Certification: | CE |
Product Description
Specifications
>high brightness>using PC of German Bell Co
>using special anti-ultraviolet non-shine process,good coherency
>UL certificate
Technical parameter:
1. LED encasulation mode: SMD 3528 Surface mounted
2. Horizontal axis: 160
3. Vertical axis: 160
4. Pixel composition: 1R1G1B
5. Pixel pitch: 8mm
6. Scan method: 1/8 scan
7. Drive method: Constant current
8. Module resolution: 32dots *16 dots
9. Module dimensions: 256*128mm
10. Module type: Integration of lamp board and drive board
11. Module working voltage: 5V
12. Average power consumption: 7 W
13. Maximum power consumption: 28 W
14. Module shell material :PC
15. Module mask material: PC
16. Splicing Screen: 3*6 pieces (module layout W*H)
