Specifications
Centrifugal fan speed 0~3900r/ minCompressor speed 0~6500r/ min
Compressor displacement 1.9CC
620W Air Conditioner ( Adjustable )
Industrial level air conditioning, that can meet the 7x24 hours of uninterrupted operation, and it designed life is 8 years.
Adopt efficient industrial air conditioning condenser, that could high efficiency to heat exchanger and have long service life.
DC inverter air conditioner, the compressor speed is 0-6500r / m and could adjustable, the fan speed 0-3900r / m and could adjustable.
The control system uses a closed loop PID regulator. According the temperature error of the target to adjust frequency and speed,
so as to achieve the stabilizing effect. This modulation technique, when the temperature is infinitely close to the target temperature,
a small power input to keep the temperature stable. Adjust the three variables of the compressor, condenser fan and evaporator fan,
to make the state to achieve the best and match for efficient output.
The air conditioner control unit with LCD display thermostat that is simple operation and intuitive display.
The controller is equipped with 6 relay outputs, respectively control of internal circulating fan, external circulating fan,
compressor, heater, remove hydrogen fan and all the way to set aside the output.
With RS485 RPOA Remote Port of Access, and with fault detection and alarm functions, it could uploaded fault alarm
information to the monitoring center through the controller.
Performance indicators |
Parameter
|
Working Power |
DC-48V |
Max. cooling capacity |
620W (Adjustable) |
Max. input power |
219W |
Average cooling capacity of the standard conditions |
487W |
Centrifugal fan speed |
0~3900r/ min |
Compressor speed |
0~6500r/ min |
Input current as Max. speed |
4.55A |
Compressor displacement |
1.9CC |
Refrigerant |
R134a |
Refrigerant charging |
115g |
Temp resolution |
0.2°C |
Noise |
60dB |
Net weight |
15kg |
Outer size (L * W * H) |
376*145*580 (mm) |
- Sample: Sample making is available before mass-manufacture.
- Delivery: 20-30 days after receipt the deposit.
- Factory Visit& Inspection: Welcome customer or your agent to visit our factory before order and loading.
Tianjin Yanxiang Electronic Science and Technology Co., Ltd., registered in Tianjin Binhai Hi-Tech industrial Zone.
It is a high-tech company with technology R&D and service combination as well as information and industry.
Meanwhile it is a High State Authenticated and New Technology Enterprise , Excellent Private Enterprise of Tianjin.
The company passed the ISO9001 International Quality System Certification in 2004 January.
We have acquired multiple software copyrights and invention patents.
Several product technologies are listed as National Key and New Product Project , Tianjin Science and Technology Support Plan Project.
1.Are you a manufacturer?
Yes.We have 13 years manufactural experience.
2.Can you ensure quality?
Yes.In the production of each link and before loading do a detailed inspection.
3.Can you keep timely delivery?
Yes.We use short producing time and fast shipping.
