multicore 16 pairs utp lan cable
Cable Data:
Conductor |
Solid bare copper,CCA,CCS,CCAG |
AWG |
24-26 |
Conductor Dia(mm) |
0.40-0.51mm |
Insulation |
PE |
Average thickness(±0.03mm) |
0.18 -0.22mm |
Min point thickness |
0.15mm |
Insulation Dia(±0.03mm) |
0.88-0.92mm |
Twisting lay length(mm) |
80 underneath |
Cabling lay length(mm) |
500 underneath |
Jacket |
PVC/LSZH/PE |
Average thickness |
0.8-2.0mm |
Min point thickness |
0.7mm |
Outer Dia(±1.0mm) |
7.5-20.1mm |
Rip cord |
YES |
Product Description:
Industrial Standards |
YD/T1019-2001,USA ANSI/TIA/EIA-568-B,WORLD WIDE ISO/IEC 11801-71156. |
Certifications |
CE/Rohs/ISO9001:2008 |
Conductor |
Solid &Stranded soft circle twisted copper wire. Other materials for conductor are available ,such as CCA,CCS,CCAM,etc. |
Conductor Diameter |
24-26AWG |
Insulation |
High-density Polythene(HDPE) |
Jacket |
Polyvinyl chloride (PVC),LSZH,PE. We can provide all kinds of colors according to customer's requirements. |
Ripcord |
Optional |
Rated Temperature |
75°C |
Compliant Network Standars |
|
Packaging detail |
1) Packing Lengths: at least 100m/ roll , Other lengths available according to client's request; 2) Inner packing: Wooden reel, plastic reel, or paper reel are available. 3) Outer packing: Carton box, pull out box, pallet are available. |
Delivery |
7-15Days after customer’s confirmed |
Remarks |
Customized packing are available, OEM&ODM order is welcomed. |
Description:
HYA communication cable is designed for the telephone exchange HYA Cable - Telecommunications Cable copper wire+ HDPE insulation+ polyester film or other braiding+ PE jacket
This cable is telephone cable designed for the telephone exchange area and relay lines,and it can be used for overhead cable and pipe laying. It is applicable to the communication lines in the city, in the suburbs and some local regions. area and the relay route. It can be used in overhead and duct. The working temperature is -30+60.
Specificationall types of the HYA type cable(≤1200 pairs) can be provided.
Application:
It can be used to transmit audio signals and digital signal of the integrated services digital network with the rate of below 2B + D-rate. It can also transmit 2048kbit /s digital signals or the analog signals (below 150KHz).
Certification:
ISO90012000, CE,ROHS
Package:
100m per roll/coil in a easy box, 2 or 3 boxes in a carton.
200m/300m/500m/1000m with wooden drun or plastic reel or as your request.
product images:
