Help Centerdc Fan 3v
US$ 0.65 - 1.5
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
DC
Mounting:
Free Standing
Blade Material:
Plastic
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Electric Current Type
DC
Mounting
Free Standing
Blade Material
Plastic
Place of Origin
Guangdong, China
Brand Name
son times
Model Number
ST2507HS
Voltage
3v 5v 12v 24v
Power
0.5W
Air Volume
15CFM
Speed
10000RPM
Certification
CE
Specifications
1.dc fan 3v2.size:25*25*7mm
3.sleeve,ball bearing
4.rated voltage:3v /5V/12V
5.airflow:10-15cfm
| Frame size(mm) | 25*25*07mm | |
| Bearing type | ball bearing/sleeve | |
| Rated voltage | 3v 5/12/24v | |
| Rated speed | 8000-10000RPM | |
| Max air flow | 10-15CFM | |
| Max pressure | 0.13-0.16inch-H2O | |
| Max noise | 16-18dBA | |
| Functions | by impedance,FG | |
| Safety approvals | CE ROHS | |
| Dielectric Strength | 5mA max at 1500VAC for 1 min between lead wire and frame | |
| Insulation resistance | 100M ohm between lead wire and frame(DC 500V) | |
| Life expectancy(ball bearing) | 70000hrs min at 40 degree C/L10 relative humidity 65%+/-20% | |
| Life expectancy(hypro bearing) | >40000hrs min at 40 degree C/L10 relative humidity 65%+/-20% | |
| Operation temperature | -10~80 degree C(+14~176 degree F) | |
| Storge temperature | -40~75 degree C(-40~167 degree F) | |
| Protection | Motor protection and polarity protection | |
| Lead wire | UL1571 AWG26,28; UL1007 AWG26,28; UL1061 AWG30 | |
| fan blade material | Black PBT (UL94V-0) glass filled | |
| frame material | PBT | |
| Weight | 5g |
dc fan 3v
