Low Noise dc Brushless Led Fan

Name: Low Noise dc Brushless Led Fan
Brand: SON TIMES
SKU: 100834585

US$ 0.3 - 1.2 MOQ: 1000 Pieces

Key Specifications

Electric Current Type:

Mounting:

Free Standing

Blade Material:

Plastic

Shenzhen Son Times Electronics & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Electric Current Type DC

Mounting Free Standing

Blade Material Plastic

Place of Origin Guangdong, China

Brand Name SON TIMES

Model Number ST4010HS

Voltage 5V12V/24V

Power 0.45-1.2W

Air Volume 15-25CFM

Speed 8000RPM

Certification CE, CE

Specifications

1.low noise dc brushless led fan
2.40*40*10mm
3.sleeve,ball bearing
4.rated voltage:5V/12V/24V
5.Low noise.long -life

Frame size(mm)	404010mm
Bearing type	hypro bearing
Rated voltage	5v/12v/24v
Rated speed	4500-9500RPM
Max air flow	10-15CFM
Max pressure	0.10-0.12inchH2O
Max noise	25-35dBA
Functions	by impedance,by IC, FG,RD,PWM
Safety approvals	CE ROHS
Dielectric Strength	5mA max at 1500VAC for 1 min between lead wire and frame
Insulation resistance	10M ohm between lead wire and frame(DC 500V)
Life expectancy(ball bearing)	7000hrs min at 40 degree C/L10 relative humidity 65%+/-20%
Life expectancy(hypro bearing)	>40000hrs min at 40 degree C/L10 relative humidity 65%+/-20%
Operation temperature	-10~75 degree C(+14~167 degree F),normal; -10~90 degree C(+14~194 degree F)
Storge temperature	-40~75 degree C(-40~167 degree F)
Protection	Motor protection and polarity protection
Lead wire	UL1571 AWG28,30; UL1007 AWG24,26; UL1061 AWG26
Plastic material	Motor protection and polarity protection
