Figure 8 Self-supporting Fiber Optical Cable GYTC8S 2-288 Cores
Product's Specification
Features
- High tensile strength of stranded wires meet the requirement of self-supporting and reduce the installation cost.
- Good mechanical and temperature performance
- High strength loose tube that is hydrolysis resistant
- Special tube filling compound ensure a critical protection of fiber
- The following measures are taken to ensure the cable watertight:
- Steel wire used as the central strength member
- Loose tube filling compound
- 100% cable core filling
- steel tape moisture barrier
Technical data
| Fiber Num. | Outer diameter (mm) | Weight (kg/km) | Tension (N) | Crash loading (N/100mm) | ||
| Short term | Long term | Short term | Long term | |||
| 2-30 | 9.5*18.2 | 150 | ≥6000 | ≥2000 | ≥1000 | ≥300 |
| 32-48 | 10.2*18.9 | 162 | ||||
| 50-60 | 10.2*19.2 | 173 | ||||
| 62-72 | 10.9*19.9 | 197 | ||||
| 74-84 | 12.1*21.1 | 217 | ||||
| 86-96 | 12.1*21.1 | 217 | ||||
Packing
3000m/wooden drum or as customized
Application
- Adopted to Outdoor distribution
- Suitable for aerial pipeline laying method
- Long distance and local area network communication
Company Info
Founded in 2002, Shenzhen ADP Cables Co., Ltd. is located in Shenzhen City, a coastal city with convenient transportation. The company specializes in production of 1mm2 to 500mm2 power cables, two cores to 288 cores of communication optical fiber cables, 1 pair to 200 pairs of communication cables, security cables, coaxial cables, other accessories, etc.
Its factory has a floor area of about 200,000 square meters. The company has constantly introduced international advanced production equipment and testing equipment to strictly control the links of its production. The company has a total staff member of more than 500 including top technical R & D talent and sale elites. The company wins high praise and wide approval from the industry by virtue of its excellent and high-quality products and service.
Its products have passed the certifications of UL, ISO9001 Quality Management System, BV, CE, ROHS, CCC, VDE, etc. The company was successively awarded “Shenzhen Top 10 E-business Members” by Alibaba in 2010 and 2011. Its export business has constantly been expanded. Its products are sold in more than 100 countries and areas. The company realizes an annual output value of USD 0.2 billion. During development, the company has established long-term cooperative relations with new and old customers around the world in the principle of “Credit, Equality, Reciprocity, Quality First, Service Supremacy”. Welcome to contact us.
