110v to 230v ac Cooling Fan

Name: 110v to 230v ac Cooling Fan
Brand: son times
SKU: 100829677
Availability: InStock

US$ 3.5 - 5 MOQ: 500 Pieces

Key Specifications

Electric Current Type:

Mounting:

Free Standing

Blade Material:

Plastic

Shenzhen Son Times Electronics & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Electric Current Type AC

Mounting Free Standing

Blade Material Plastic

Place of Origin Colombia

Brand Name son times

Model Number ST17251B

Voltage 110-380V

Power 42.9-52.3W

Air Volume 150-190CFM

Speed 2300-2800RPM

Certification CE

Specifications

1.110v to 230v ac cooling fan
2.size:172*172*51mm
rrosionproof
4.operating life:3years
5.two bearings.large airflow

ac 110v cooling fan

	Frame size	17217251mm
	Bearing type	ball bearing.sleeve
	Rated voltage	115V/50,60HZ, 230V/50,60HZ
	Rated speed	2300-2800RPM
	Max air flow	150-190CFM
	Max pressure	11-13
	Max noise	52-54
	Functions	by IC, by IC with FG, by IC with RD
	Safety approvals	CE ROHS
	Dielectric Strength	5mA max at 1500VAC for 1 min between lead wire and frame
	Insulation resistance	100M ohm between lead wire and frame(DC 500V)
	Life expectancy(ball bearing)	70000hrs min at 40 degree C/L10 relative humidity 65%+/-20%
	Life expectancy(hypro bearing)	>40000hrs min at 40 degree C/L10 relative humidity 65%+/-20%
	Operation temperature	-10~80 degree C(+14~176 degree F)
	Storge temperature	-40~75 degree C(-40~167 degree F)
	Protection	Motor protection and polarity protection
	Lead wire	UL1571 AWG28,30; UL1007 AWG24,26; UL1061 AWG26
	Plastic material	Black PBT (UL94V-0) glass filled
