Help CenterSteel Driveway Grating
Related Products
-
Catwalk Steel GratingUS$ 10 - 30MOQ: 200 Square Meters -
Steel Grating (Low Prices)US$ 10 - 30MOQ: 200 Square Meters
-
Galvanized Steel Concrete Drainage GratingUS$ 3.42 - 37.62MOQ: 100 Square Meters
-
Galvanized Steel Flooring GratingUS$ 3.42 - 37.62MOQ: 100 Square Meters
-
Galvanized Drainage Steel GratingUS$ 3.42 - 37.62MOQ: 100 Square Meters
Specifications
Steel GratingMaterial:Stainless Steel,low-carbon steel etc
Type:Serrated,Plain,I shape
Beautiful appearance
ISO9001,SGS
Steel grates
1.Material:
a.flat bar(bearing bar or load bar): low-carbon steel,stainless steel,aluminum alloy etc
b.cross bar:Q235 or other equivalent material
2.Surface Treatment:
Galvanized,painted,untreated,etc.
3.shape:
a. flat bar(bearing bar or load bar) surface shape: Serrated,Plain,I shape
b.cross bar:round shape and square twisted shape,etc.
4.Grating Dimension:
1) Flat bar(bearing bar or load bar)specifications (mm):
The specification of plain shape and serrated shape flat bar is 20*3 to 100*6;
The specification of I-shape is 25*5*3,32*5*3,38*5*3,40*5*3,50*5*3,50*7*4,55*7*4,60*7*4,65*7*4,70*7*4,75*7*4,etc.
2)Flat bar pitch (center to center):
12.5,15,30,34,40,60mm etc,also be according to client's requirement and 30,40, 60mm are recommended,
3)Cross bar pitch (center to center):
38,50,76,100,101.6mm etc,also be according to client's requirement and 50,100mm are recommended.
The sizes and dimension is not limited to above.
6.application:
Widely used in steel structure platforms,stair treads,sidewalks,drainages and well covers etc.We can manufacture standard steel grating and in customized shapes as your requirements.
