stainless steel I-shaped edge covering steel bar grating

Specifications

I-shaped flat bar garting
1.material: stainless steel
2.surface shape: I-shaped
3.manufacturer
4.ISO9001

  stainless steel I-shaped edge covering steel bar grating





Material:



Bearing bar: low carbon stee, stainless steel, aluminium alloy

Cross bar: Q235A/304 stainless steel twisted square steel, square steel, round steel, flat steel, etc.



Flat bar surface shepe:  flat shape, tooth shape, I-shape, I tooth shape





Detailed specification:



1.Flat Bar Specification



1)Plane Flat Bar Specification:



a Thickness:3mm, 5mm
b Height: 25mm, 30mm, 32mm, 40mm, 45mm, 50mm,  60mm, etc.



2) I-shaped Flat BarSpecification:



a Thickness of both ends: 5mm;
b Thickness of the center: 3mm;
c Height: 25mm, 32mm, 38mm, 44mm, 50mm, etc.



2: Flat Bar Spacing: 30mm,40mm,60mm. dense grating <25mm.

3: Cross Bar Specification: 5×5, 6×6, 8×8mm.

4: Cross Bar Spacing: 50mm,100mm



5: Length of Steel Grating Plate: ≥800mm.or 3000—10000mm.

6: Surface Treatment: electro galvanized, hot dipped galvanized, paint spray, leaching rust-proof oill, etc.



Aplication: Main used for steel flat pallet, steel ladder step plat, steel grating fencing,  NF-SGG, etc.



Characteristic:  Ventilation, lighting, cooling, prevent slippery, explosion-proof performance, etc
