54′′ Ventilation Fan Direct Drive Type
Products Features
1) Fan Frame: made from highly galvanized steel sheets in order to assure highest strength and strong resistance to corrosion.
2) Blade: 6 pieces stainless steel blades and the fan has all passed the experiment of homeostasis with big air volume, without deformation n, no breaking, attractive and durable.
3) Belt Pulley: The V type belt pulley is aluminum magnesium alloy injection molded, light weight, high-strength.
4) Bearing: France imported bearing, high intensity, low noise, long service life.
Model |
Diameter Blades(mm) |
Air Volume m3/h |
Power KW |
Outer Size(mm) |
Voltage |
Frequency |
ZYA-1000 |
900 |
32000 |
0.75 |
1000*1000*400 |
380V |
50HZ |
ZYA-1100 |
1000 |
35000 |
0.75 |
1100*1100*400 |
380V |
50HZ |
ZYA-1220 |
1100 |
40000 |
0.75 |
1220*1220*400 |
380V |
50HZ |
ZYA-1380 |
1250 |
44000 |
1.1 |
1380*1380*400 |
380V |
50HZ |
ZYA-1530 |
1400 |
55800 |
1.5 |
1530*1530*400 |
380V |
50HZ |
Fan Parts:
Adopt the Aluminum Magnesium Alloy pulley and blade impeller:
Adopt automatic belt tensioner,make fan work smoothly:
Fanblades in Stainless Steel,no broken,long service life:
Installation Effect
|
|
|
|
|
|
ZY Series Fan:
