Hot dip galvanized hexagonal wire mesh| gabion basket retaining wall
Gabion box application: Bank stabilization; Reinforcement of soils; Strengthening of slopes and embankments; Protection against rockfalls, avalanches, debris flows; Retaining walls; Protection of subsea pipelines; Landscape Design; Strengthening of the bottom waters and sea ports.
Specifications of Gabion Basket:
1. Aperture: 60x80mm 80x100mm 80x120mm 100x120mm 120x150mm
2. Wire Diameter:
(1) Mesh wire diameter range: 2mm-4mm
(2) Edge wire diameter range: 2.7mm-4.4mm
(3) Binding wire diameter range less than mesh wire, in 2.2mm generally.
3. Wire tensile strength: not less than 38kg/m2, 380N/mm.
4. Surface Treatment:
(1) Electro galvanized, zinc coating is Max. 10g/m2, with bad performance of anti-corrosion
(2) Hot-dip galvanized Zinc coating is Max. up to 300g/m2, with better performance of anti-corrosion
(3) Galan (zinc-aluminium alloy), including zinc-5% Al mixed rare earth alloy wire and Zinc-10% Al mixed rare earth alloy wire, the best performance of anti-corrosion.
(4) PVC coated, PVC coating is 1.0mm generally.
5. Diaphragm: 1 diaphragm every 1 meter is located in the direction of length of gabions.
6. Dimension: 2mx1mx1m, 3mx1mx1m, 4mx1mx1m, 2mx1mx0.5m, 4mx1mx0.5m,offer sizes as per clients' requirements.
7. Characteristic: economy, easily to be installed, A strong performance of withstanding natural damage, corrosion resistance, good permeability, stacked to save transportation cost.
|
Opening (mm) |
Wire diameter (metal wire) (mm) |
Wire diameter (PVC coated Inner and Outer wire) (mm) |
Strands
|
Dimension LengthxWidthxHeight (m) |
|
60X80
|
φ2.0-2.8
|
φ2.0/3.0-2.5/3.5
|
3 |
1. 2mx1mx0.5 m; 2. 2mx1mx1 m; 3. 3mx1mx1m; 4. 4mx1mx1m; 5. 4mx1mx0.5m. |
|
80X100
|
φ2.0-3.2
|
φ2.0/3.0-2.8/3.8
|
3 |
|
|
80X120
|
φ2.0-3.2
|
φ2.0/3.0-2.8/3.8
|
3 |
|
|
100X120
|
φ2.0-3.4
|
φ2.0/3.0-2.8/3.8
|
3 |
|
|
100X150
|
φ2.0-3.4
|
φ2.0/3.0-2.8/3.8
|
3 |
|
|
120X150
|
φ2.0-4.0
|
φ2.0/3.0-3.0/4.0
|
3 |
