Product Details
Gabion baskets are wire fabric containers, filled with stone at the site of use, to form flexible, permeable, monolithic structures for earth retention.
Material: High quality low carbon steel wire, galvanized wire, stainless steel wire, PVC coated wire
Feature: Link and weaving is simple, artistic and practical
Standard: ASTM-975-97 and BS EN 10223-2:1998
Wire diameter: 1.6mm--4mm (mainly according to your requirement)
Aperture size(mm): 60x80 80x90 80x100 80x120 100x120 100x150 120x150 120x180 180x200
Yearly Output: more than six million square meters.
Gabion Box Specification Table | |||
|
Opening (mm) |
Wire Diameter(Steel Wire) |
Wire Diameter(PVC Coated) |
Strands |
60X80 |
2.00-2.80 |
2.0/3.0-2.5/3.5 |
3 |
80X100 |
2.00-3.20 |
2.0/3.0-2.8/3.8 |
3 |
80X120 |
2.00-3.20 |
2.0/3.0-2.8/3.8 |
3 |
100X120 |
2.00-3.40 |
2.0/3.0-2.8/3.8 |
3 |
100X150 |
2.00-3.40 |
2.0/3.0-2.8/3.8 |
3 |
120X150 |
2.00-4.00 |
2.0/3.0-3.0/4.0 |
3 |
Advantage
• Economic.
• Just fill the stone into the gabion and seal it.
• Simple installation.
• No special technology needed.Weather proof under natural destroy, corrosion resistant.
• No collapse even under big scope of deforming.
• Sludge in the stones is good for plant growing.
• Mixed to form a integrity with the natural environment.Good permeation can prevent the damage by hydrostatic.
• Less transport freight. It can be folded together for transport and further installation.
Gabion Basket Application
• Control and guide of water or flood
• Flood bank or guiding bank
• Preventing of rock breaking
• Bridge Protection
• Water and soil protection
• Coast protection
• Seaport engineering
• Strengthening structure of soil
• Protection of road
