Galvanized Hexagonal Mesh Gabion Box

Galvanized Hexagonal Mesh Gabion Box photo-1
US$ 1.5 - 2.9 MOQ: 5000 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Hexing
Model Number:
GHGB/80x100/2x1x1
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name Hexing
Model Number GHGB/80x100/2x1x1
Material Other, Galvanized Iron Wire, Galvanized Iron Wire
Type Other, Welded Mesh, Chain Link Hexagonal Mesh
Application Gabions
Hole Shape Square
Aperture 75x75mm
Wire Gauge 3mm 4mm



galvanized hexagonal mesh gabion box





Gabion box, gabion mattress, gabion basket, stone cage and gabion wall are unfolded and laid on prepared ground. Creases in the boxes can be easily stamped out and levelled manually. Individual sheets are straightened flat and then systematically folded to form an exact rectangular shape. All the sides, diaphragms are laced with lacing wire with lacing procedure. Boxes or group of laced boxes are placed at the required location to match the structural design accurately.



We can supply various kinds of gabion box with mesh openings of 60x80, 80x100, 80x120, 80x140, 100x120, 120x150 and 200x260mm, and wire thicknesses ranging from 2.00mm to 3.4mm. The possible coatings are Heavy Galvanized coat (BS1052/80, EN10244-2, DIN1548 and ASTMA975-97) and Zinc Al.


For high corrosion resistance, PVC coated wire is available. That is to say, the mesh wire can be made depending on the application and the requirement.



Opening

(mm)

Wire diameter

(metal wire)

(mm)

Wire diameter

(PVC coatedInner

and Outer wire)

(mm)

Strands

Dimension

LengthxWidthxHeight

(m)

60X80

φ2.0-2.8

φ2.0/3.0-2.5/3.5

3

1. 2mx1mx0.5 m;

2. 2mx1mx1 m;

3. 3mx1mx1m;

4. 4mx1mx1m;

5. 4mx1mx0.5m.

80X100

φ2.0-3.2

φ2.0/3.0-2.8/3.8

3

80X120

φ2.0-3.2

φ2.0/3.0-2.8/3.8

3

100X120

φ2.0-3.4

φ2.0/3.0-2.8/3.8

3

100X150

φ2.0-3.4

φ2.0/3.0-2.8/3.8

3

120X150

φ2.0-4.0

φ2.0/3.0-3.0/4.0

3

 galvanized hexagonal mesh gabion boxgalvanized hexagonal mesh gabion boxgalvanized hexagonal mesh gabion box
