Hot-dipped Galvanized Heavy Type Diamond Expanded Metal Mesh

Specifications

Diamond expanded metal
Thickness 0.5-8mm
Type Mini-hole, standard and heavy
Surface treatment: PVC coated, hot dipped galvani

Diamond Expanded Mesh

Material: Low Carbon Steel Plate, Aluminium Plate, Stainless Steel Plate, Titanium Plate, Alum-Platinum Plate, Lead Plate, Nickel Plate, etc.

Surface treatment: PVC coated, hot dipped galvanized, electro galvanized, anodic oxidation, antirust painting etc.
Main Processes: Punching and Pulling.
Type: Mini-holed, Standard and Heavy.

Variety according to application:
auto grille;
expanded mesh fence;
Barbecue Wire Mesh;
expanded mesh for ceiling;
used in wall for anti-cracking, shakeproof;
in soil-nail wall supporting structure instead of B.R.C wire mesh;
expanded metal used in ship platform (thickness 3mm-8mm, hole 30x60mm-50x100mm, width 02m-2m, hot rolled sheet);
loudspeaker box protection mesh (material: black sheet, galvanized sheet, hole 2x32x43x6, thickness 0.3-0.5mm);
for scaffold (hot rolled plate, thickness: 2mm-5mm, surface treatment: hot dipped galvanized, characteristic: antiskid, sturdy and durable)



Standard Specification of Diamond Expanded Metal Mesh
Thickness(mm)	SWD(mm)	LWD(mm)	strand width(mm)	Width(mm)	Length(mm)	Weight(kg/m2)
0.5	2.5	4.5	0.5	0.5	1	1.8
0.5	10	25	0.5	0.6	2	0.73
0.6	10	25	1	0.6	2	1
0.8	10	25	1	0.6	2	1.25
1	10	25	1.1	0.6	2	1.77
1	15	40	1.5	2	4	1.85
1.2	10	25	1.1	2	4	2.21
1.2	15	40	1.5	2	4	2.3
1.5	15	40	1.5	1.8	4	2.77
1.5	23	60	2.6	2	3.6	2.77
2	18	50	2.1	2	4	3.69
2	22	60	2.6	2	4	3.69
3	40	80	3.8	2	4	5.00
4	50	100	4	2	2	11.15
4	60	120	4	2	7.5	4.0
4	80	180	4	2	10	3.0
4	100	200	4	2	12	2.5
4.5	50	100	5	2	2.7	11.15
5	50	100	5	1.4	2.6	12.39
5	75	150	5	2	10	3.0
6	50	100	6	2	2.5	17.35
8	50	100	8	2	2.1	28.26
