Home > Products > Expanded Metal Mesh > Diamond Hole Expanded Metal Mesh, Heavy Type
Diamond Hole Expanded Metal Mesh, Heavy Type
- Tianjin Port
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | Hexing | |
| Model Number | HTEM-50-100 | Material | Other, Mild Steel, galvanized steel, stainless steel, aluminum |
Product Description
Specifications
Heavy Type Expanded MetalDiamond shape hole
thickness 3mm-8mm,
hole 30x60mm-50x100mm,
width 0.2m-2m, hot rolled steel sheet
Diamond Hole Expanded Metal Mesh, Heavy Type
Material: Low Carbon Steel Plate, Aluminium Plate, Stainless Steel Plate, Titanium Plate, Alum-Platinum Plate, Lead Plate, Nickel Plate, etc.
Surface Treatment: PVC coated, hot dipped galvanized, electro galvanized, anodic oxidation, antirust painting etc.
Main Processes: Punching and Pulling.
Type: Mini-holed, Standard and Heavy.
Variety according to application:
auto grille;
expanded mesh fence;
Barbecue Wire Mesh;
expanded mesh for ceiling;
used in wall for anti-cracking, shakeproof;
in soil-nail wall supporting structure instead of B.R.C wire mesh;
Expanded metal used in ship platform (thickness 3mm-8mm, hole 30x60mm-50x100mm, width 0.2m-2m, hot rolled sheet);
loudspeaker box protection mesh (material: black sheet, galvanized sheet, hole 2x32x43x6, thickness 0.3-0.5mm);
for scaffold (hot rolled plate, thickness: 2mm-5mm, surface treatment: hot dipped galvanized, characteristic: antiskid, sturdy and durable)
Standard Specification of Diamond Expanded Metal Mesh | ||||||
Thickness(mm) | SWD(mm) | LWD(mm) | strand width(mm) | Width(mm) | Length(mm) | Weight(kg/m2) |
0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 |
0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 |
0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 |
0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 |
1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 |
1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 |
1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 |
1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 |
1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 |
1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 |
2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 |
2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 |
3 | 40 | 80 | 3.8 | 2 | 4 | 5.00 |
4 | 50 | 100 | 4 | 2 | 2 | 11.15 |
4 | 60 | 120 | 4 | 2 | 7.5 | 4.0 |
4 | 80 | 180 | 4 | 2 | 10 | 3.0 |
4 | 100 | 200 | 4 | 2 | 12 | 2.5 |
4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 |
5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 |
5 | 75 | 150 | 5 | 2 | 10 | 3.0 |
6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 |
8 | 50 | 100 | 8 | 2 | 2.1 | 28.26 |
