Help CenterStainless Steel Decorative Mesh Metal Building Materials Woven by Flat Wire
Related Products
-
Woven Wire Mesh Decorative Wire Mesh Metal Decorative MaterialsUS$ 105 - 145MOQ: 100 Square Meters -
Stainless Steel| Copper Curtain Wall Decorative MeshUS$ 150 - 190MOQ: 30 Square Meters
-
Metal Spiral Net/ Flat Wire Conveyor BeltUS$ 28 - 98MOQ: 10 Meters
-
Metal Net Curtain/ Flat Wire Decorative MeshUS$ 28 - 98MOQ: 10 Meters
-
Metal Decorative Net CurtainUS$ 28 - 98MOQ: 10 Meters
Specifications
Material: SUS 304, 316, 316LFlat Strip: 0.25" wide x 0.039" thick
Opening: 0.280" x 0.280"
Center-to-center flat strip 0.53"
Stainless steel decorative mesh metal building materials woven by flat wire is made by high quality material, two sides are polished finish. Various specifications on flat wire width and thickness, to different senses of vision. Metal flat wire decorative wire mesh has the characteristics of corrosion resistance, high temperature resistance, uniform mesh, good toughness, high strength, antioxidant etc. Owning the advantages of smooth operation, flexible using, long operating life etc.
Metal Flat Wire Decorative Wire Mesh Specification:
Material: SUS 304, 316, 316L
HX-FWM-001
Warp Wire: width 1.5mm x thickness 2.0mm
Warp Wires distance: 9.3mm
Weft Wire: width 1.5mm x thickness 2.0mm
Weft Wires distance: 2.5mm
Weight: 11.6 kg/m2
HX-FWM-002
Warp Wire: width 3.4mm x thickness 1.1mm
Warp Wires distance: 6.6mm
Weft Wire: width 3.4mm x thickness 1.1mm
Weft Wires distance: 6.6mm
Weight: 11.55 kg/m2
HX-FWM-003
Warp Wire: width 1.5mm x thickness 6.0mm
Warp Wires distance: 12mm
Weft Wire: width 1.5mm x thickness 6.0mm
Weft Wires distance: 12mm
Weight: 12.23 kg/m2
HX-FWM-004
Warp Wire: width 2mm x thickness 1mm
Warp Wires distance: 3mm
Weft Wire: width 1.8mm x thickness 0.8mm
Weft Wires distance: 6mm
Flat Strip: 0.25" wide x 0.039" thick
Opening: 0.280" x 0.280"
Center-to-center flat strip: 0.53"
