Nutritional Baby Food Making Machines to Uganda

Nutritional Baby Food Making Machines to Uganda photo-1
US$ 1,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
AMC
Model Number:
AMC85
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name AMC
Model Number AMC85
Type Other, Baby food machinery

Specifications

Nutritional baby food machine
1. Twin screw extruder
2. baby food, FBF, etc
3. Capacity: 150kg/h, 240kg/h,500kg/h

Nutritional baby food production line

1. Description:

Baby food machinery is used to produce infant baby food and some other instant flour products. The raw material is put in the mixer then mixed ingredients are fed into extruder feeder. The extruder is fitted with: special cylindrical holding silo; vibratory doser with hopper to feed the extruding screw; extrusion mechanism and cutting; independent electric panel.
After the extrusion the product is conveyed till the continuous rotary drier through a pneumatic conveyor. The continuous rotary drier has a heat exchanger with gas burner that allows a better heating of the product and it is economically viable owing the low cost of electric power. Case the client prefers we have the electric drier also.

2. Raw materials: adopts cereals flour (corn, wheat, rice, oat, soy, etc)



3. Products: baby food, FBF, CSB and samaposha etc





4. Capacity: 150kg/h, 240kg/h, 500kg/h

5. Flow chart: Mixing system---Extrusion system---- -Drying system----Milling system---Packing system



6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries



7. Machines Materials: All the machines are made by stainless steel



8. Technical Parameters

Model

Installed power

Real power

Output

Dimension

AMC65

66kw

50kw

100-150kg/h

19000x1200x2200mm

AMC70

100kw

67kw

200-240kg/h

21000x1500x2200mm

AMC85

130kw

80kw

400-500kg/h

30000x3500x4300mm



9. Sample pictures

 Nutritional baby food making machines to UgandaNutritional baby food making machines to Uganda
