Specifications
Corn snacks machine1. Twin Screw Extruder
2. Raw materials: all kind of grains
3. different dies, different shapes
Corn snacks machine
1. Description:
This process line adopts advanced extruding technique which can extrude snacks with different textures and tastes out of double-screw extruder. By changing moulds and assistant equipments, it can also produce nutritional powder, grain gruel and many other leisure snacks in different shapes. This automatic process line is of leading level for its superior characters, such as, "applied to many materials, convenient operation and maintenance, low power consumption, high output.
2. Raw materials: adopts corn, rice, wheat, oat, barley etc as ingredients
3. Products: Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart shape by adjusting the mould in the extruder
4. Capacity: 150kg/h, 240kg/h, 500kg/h
5. Flow chart: Mixing system---Extrusion system---- -Drying system----Flavoring system---Packing system
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries
7. Machines Materials: All the machines are made by stainless steel
8. Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
AMC65 |
81.5kw |
53kw |
100-150kg/h |
21000x1200x2200mm |
AMC70 |
115kw |
76kw |
200-240kg/h |
23000x1500x2200mm |
AMC85 |
181kw |
117kw |
400-500kg/h |
28000x3500x4300mm |
9. Why you choose us
a. Mainly products
1. The screw is made of alloy (38CrMoAL) by nitriding process, high strength and wear-resting. And it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.
2. The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.
3. Radiator is increased on driving part for forced cooling effect, and it ensures extruder operate safely.
4. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
5.The gearbox has automatic lubrication function, with extends gear life.
6. Main Motor from Siemens(China), ensure its Powerful Extrusion and Excellent Performance.
b.Customers and us
c. Our Quality
