Adhesive Corn Tapioca Pregelatinization Starch Processing Line

Specifications

Corn Tapioca Pregelatinization Starch Processing Line
1. Twin screw extruder
2. oil drilling starch, Pre-gelatinized starch

Adhesive Corn Tapioca Pregelatinization Starch Processing Line



1. Description:

Adhesive Corn Tapioca Pregelatinization Starch Processing Line  can produce Denatured Starch, Pre-gelatinized starch is an effective and economical fluid loss agent in water based drilling fluids, which is a starch derivative. It is not bacterial degradation when at 120°C, environmentally acceptable and non-toxic. Modified Starch can produce a thin, slick, tough filter cake and promotes faster penetration rates with reducer friction. It can be used in all kinds of drilling fluid system. Pre-gelatinized starch is also sometimes "pregelatinized" to make them easier to dissolve during product manufacture. Modified starch is widely used in oil drilling, textile, paper and food industries.



2. Raw materials: corn starch, cassava starch, potato starch



3. Products: oil drilling starch, Pre-gelatinized starch



4. Capacity:  300kg/h, 500kg/h, 1ton/h, 2ton/h



5. Flow Chart: Mixing---Extrusion---Drying---Grinding---Blending—Packing



6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries



7. Machines Materials: All the machines are made by stainless steel



8. Technical Parameters

Model	Installed power	Real power	Output	Dimension
AMC85	145kw	100kw	300-400kg/h	20000x2000x3500mm
AMC90	135kw	90kw	600-800kg/h	22000x2000x3500mm
AMC120	155kw	110kw	1500-2000kg/h	24000x3500x4500mm
AMC130	235kw	165kw	2000-3000kg/h	30000x3500x4500mm



9. Pictures
