Specifications
Pre-gelatinized starch machinery1. Twin screw extruder
2. oil drilling starch, Pre-gelatinized starch
Pregelatinized starch machines
1. Description:
Pre-gelatinized starch machinery can product Denatured Starch, Pre-gelatinized starch is an effective and economical fluid loss agent in water based drilling fluids, which is a starch derivative. It is not bacterial degradation when at 120°C, environmentally acceptable and non-toxic. Modified Starch can produce a thin, slick, tough filter cake and promotes faster penetration rates with reducer friction. It can be used in all kinds of drilling fluid system. Pre-gelatinized starch is also sometimes "pregelatinized" to make them easier to dissolve during product manufacture. Modified starch is widely used in oil drilling, textile, paper and food industries.
2. Raw materials: corn starch, cassava starch, potato starch
3. Products: oil drilling starch, Pre-gelatinized starch
4. Capacity: 500kg/h, 1ton/h, 2ton/h
5. Flow Chart: Mixing---Extrusion---Drying---Grinding---Blending—Packing
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries
7. Machines Materials: All the machines are made by stainless steel
8. Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
AMC85 |
145kw |
100kw |
300-400kg/h |
20000x2000x3500mm |
AMC90 |
135kw |
90kw |
600-800kg/h |
22000x2000x3500mm |
AMC120 |
155kw |
110kw |
1500-2000kg/h |
24000x3500x4500mm |
AMC130 |
235kw |
165kw |
2000-3000kg/h |
30000x3500x4500mm |
9. Samples pictures
