Specifications
1.Seamless Titanium alloy tube2.Material GR1 GR2 GR5 GR7 GR12
3.Competitive Price and Good Quality
4.Hydraulic Test or 100%
SAITE Titanium Pipe/Tube/Tubing
1. Titanium Pipe, Titanium Tube
Item name |
Titanium Pipe |
Standard |
ASTM B337,ASTM B338,ASTM B861,ASTM B862 |
Material |
Gr1,Gr2,Gr3,Gr4,Gr5,Gr7,G9,Gr12,Gr23 |
Length |
can be customized |
Application |
Chemical processing,Oil and chemicals,medical industry etc |
Packaging |
Plywood case lined with foam or as per clients requirements |
Payment |
T/T in advance or Irrevocable L/C at sight |
MOQ |
20Kg |
Leadtime |
Within 15 days based on MOQ after deposit |
Payment terms |
Payment terms: T/T or Irrevocable L/C at sight |
Seamless Titanium alloy tube Gr5
We are one of the professional titanium mill product manufactuers and certified to ISO 9001:2000, we are be able to supply titanium products with
full range of sizes in all grades under ASTM,ANSI,DIN,JIS with high quality and competitive
price.
Seamless titanium tube. ISO certificate is your order's premise.You can trust us.
power and chemical plant,autumotive components,sports,marine corrosion
Titanium tube,Titanium pipe,Gr2 titanium tube
1. Standard:ASTM B337,ASTM B338,ASTM B861,ASTM B862
2. Certificate:ISO 9001,SGS report,Material and Test report.
3. Chemical requirements
 |
N |
C |
H |
Fe |
O |
Al |
V |
Pa |
Mo |
Ni |
Ti |
Gr 1 |
0.03 |
0.08 |
0.015 |
0.20 |
0.18 |
/ |
/ |
/ |
/ |
/ |
bal |
Gr 2 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
/ |
/ |
bal |
Gr 3 |
0.05 |
0.08 |
0.015 |
0.30 |
0.35 |
/ |
/ |
/ |
/ |
/ |
bal |
Gr 5 |
0.05 |
0.08 |
0.015 |
0.40 |
0.20 |
5.5~6.75 |
3.5~4.5 |
/ |
/ |
/ |
bal |
Gr 7 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
0.12~0.25 |
/ |
/ |
bal |
Gr 9 |
0.03 |
0.08 |
0.015 |
0.25 |
0.15 |
2.5~3.5 |
2.0~3.0 |
/ |
/ |
/ |
bal |
Gr12 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
0.2~0.4 |
0.6~0.9 |
bal |
4. Tensile requirements
grade |
Tensile strength(min) |
Yeild strength(min) |
Elongation(%) |
||
ksi |
MPa |
ksi |
MPa |
||
1 |
35 |
240 |
20 |
138 |
24 |
2 |
50 |
345 |
40 |
275 |
20 |
3 |
65 |
450 |
55 |
380 |
18 |
5 |
130 |
895 |
120 |
828 |
10 |
7 |
50 |
345 |
40 |
275 |
20 |
9 |
90 |
620 |
70 |
438 |
15 |
12 |
70 |
438 |
50 |
345 |
18 |
5. Available dimensions of titanium tube
Outside Diameters:5m to 150mm (seamless tube)
Wall thickness:0.5mm to 7mm
Length:1 meter to 12 meters
Outside Diameters:55m to 914mm (welding tube)
Wall thickness:2mm to 10mm
Length:1 meter to 6 meters
If you have any questions,pls feel free to contact us
Sincerely looking forward to your reply
