CR43-1R0MC DS1145-8R2M ELL-4GM330M LAV35VB561J FLF3215T-220M 822MY-151K

Name: CR43-1R0MC DS1145-8R2M ELL-4GM330M LAV35VB561J FLF3215T-220M 822MY-151K
Brand: original
Availability: InStock

FOB Price

US$ 0.001 - 0.002 / Piece

1 Piece(Min. Order)

Port shenzhen/hongkong
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

D/C	Status In own stock	Package	Pls email to us, All kinds of package can supply
Model Number	CR43-1R0MC DS1145-8R2M ELL-4GM330M	Type	Other, Professional BOM distributor, Professional IC distributor
Brand Name	original	Place of Origin	American Samoa

Product Description

CR43-1R0MC DS1145-8R2M ELL-4GM330M LAV35VB561J FLF3215T-220M 822MY-151K

Product description

CR43-1R0MC
FIXED IND 1UH 2.56A 48.7 MOHM
Standard Package	Tape & Reel (TR)
Series	CR43
Type	Wirewound
Material - Core	Ferrite
Inductance	1µH ±20%
Current Rating	2.56A
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	48.7 mOhm Max
Q @ Freq	-
Frequency - Self Resonant	152.8MHz
Operating Temperature	-40°C ~ 100°C
Frequency - Test	7.96MHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.189" L x 0.169" W (4.80mm x 4.30mm)
Height - Seated (Max)	0.138" (3.50mm)

DS1145-8R2M
FIXED IND 8.2UH 1.75A 80 MOHM
Standard Package	Tape & Reel (TR)
Series	DS1145, Coev
Type	-
Material - Core	-
Inductance	8.2µH ±20%
Current Rating	1.75A
Current - Saturation	1.75A
Shielding	Shielded
DC Resistance(DCR)	80 mOhm Max
Q @ Freq	-
Frequency - Self Resonant	-
Operating Temperature	-40°C ~ 85°C
Frequency - Test	100kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.421" L x 0.323" W (10.70mm x 8.20mm)
Height - Seated (Max)	0.177" (4.50mm)

ELL-4GM330M
FIXED IND 33UH 300MA 700 MOHM
Standard Package	Tape & Reel (TR)
Series	M
Type	Wirewound
Material - Core	-
Inductance	33µH ±20%
Current Rating	300mA
Current - Saturation	-
Shielding	Shielded
DC Resistance (DCR)	700 mOhm
Q @ Freq	-
Frequency - Self Resonant	-
Operating Temperature	-
Frequency - Test	100kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.149" L x 0.149" W (3.80mm x 3.80mm)
Height - Seated (Max)	0.059" (1.50mm)

LAV35VB561J
FIXED IND 560UH 75MA 19 OHM TH
Standard Package	Tray
Series	LA
Type	-
Material - Core	-
Inductance	560µH ±5%
Current Rating	75mA
Current - Saturation	-
Shielding	Unshielded
DC Resistance(DCR)	19 Ohm Max
Q @ Freq	50 @ 796kHz
Frequency - Self Resonant	3MHz
Operating Temperature	-25°C ~ 105°C
Frequency - Test	796kHz
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.236" Dia (6.00mm)
Height - Seated (Max)	0.315" (8.00mm)

FLF3215T-220M
FIXED IND 22UH 600MA 450 MOHM
Standard Package	Tape & Reel (TR)
Series	FLF
Type	Wirewound
Material - Core	Ferrite
Inductance	22µH ±20%
Current Rating	600mA
Current - Saturation	450mA
Shielding	Shielded
DC Resistance (DCR)	450 mOhm
Q @ Freq	-
Frequency - Self Resonant	14MHz
Operating Temperature	-40°C ~ 125°C
Frequency - Test	1MHz
Mounting Type	Surface Mount
Package / Case	1210 (3225 Metric)
Size / Dimension	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)	0.065" (1.65mm)

822MY-151K
FIXED IND 150UH 420MA 540 MOHM
Standard Package	Bulk
Series	8RHB2
Type	Wirewound
Material - Core	-
Inductance	150µH ±10%
Current Rating	420mA
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	540 mOhm Max
Q @ Freq	-
Frequency - Self Resonant	3.2MHz
Operating Temperature	-
Frequency - Test	1kHz
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	-
Height - Seated (Max)	-

Packing & shipping

Our Services

Quality Warranty: 1. All parts send have checked before shipment.

2. We offer quality assurance for 30-360days.

3. The parts only new and original.

Payment Mothods : 1. Bank wire transfer

2. Alipay

3. Western Union

4. Escrow

5.Paypal

DGT Ltd as a professional Electronic wholesaler for one-stop service of electronic components. Competitive price advantage help to save your purchase cost and your precious time.
