Bridgelux Chip COB Light Source Low Power Led Street Light

Name: Bridgelux Chip COB Light Source Low Power Led Street Light
Brand: MCLED
SKU: 100750099

US$ 1 - 100 MOQ: 1 Piece

Key Specifications

LED Light Source:

COB

Input Voltage(V):

AC85-265V

Lamp Power(W):

Zhejiang Mingchuang Optoelectronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo China

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source COB

Input Voltage(V) AC85-265V

Lamp Power(W) 40

Lamp Luminous Flux(lm) 4400

Lamp Luminous Efficiency(lm/w) 110

Color Temperature(CCT) Other, 3000-7000k

Working Temperature(℃) -40, 60

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP67

Certification CCC, CE, CQC, EMC, LVD, PSE, SAA

Warranty(Year) 5

Place of Origin Zhejiang, China

Brand Name MCLED

Model Number ML018

bridgelux chip COB light source low power LED street lights

Apply to Roads, Highway, Highway Lighting, Bridge, Car Park, Garden, Park, Petrol Station, Sport Lighting, Square

Product Description

Model Item	ML018-LED street light
LED Consumption	20W-40W
System Consumption	LED Power*1.1
Input Voltage	AC 100-265 V
Working Power Frequency Range	47-63HZ
Power Factor	>0.95
Total Harmonic Distortion	<15%
Working Environment	Temperature:-40℃~60℃; Humidity: 0~100%
Average Temperature in 24 hrs	≤35 °c
Surface Highest Temperature	≤60°c
Junction Temperature(TJ)	≤70°c
Lamp Luminous Efficacy(Lm/W)	≥110LM/W
LED Initial Flux (Lm)	LED POWER*110LM
Lamp Efficiency(%)	≥90%
Color Temperature	2500K~7000K
Color Rendering Index(CRI)	Ra›75
LED Life Span	>5000h
Protection Grade	IP67
Lens Light Transmittance	≥90%
Beam Angle	60°-160°
Net weight	5.0KG
Gross weight	6.0KG
Packing size	L76W31.5H23 CM
Note:Lens can be changed according to client's specific requirement.
