Bridgelux Led Chip High Quality IP 67 Led Street Light

Name: Bridgelux Led Chip High Quality IP 67 Led Street Light
Brand: MCLED
SKU: 100750141

US$ 1 - 100 MOQ: 1 Piece

Key Specifications

LED Light Source:

COB

Input Voltage(V):

AC85-265V

Lamp Power(W):

100

Zhejiang Mingchuang Optoelectronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo China

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source COB

Input Voltage(V) AC85-265V

Lamp Power(W) 100

Lamp Luminous Flux(lm) 11000

Lamp Luminous Efficiency(lm/w) 110

Color Temperature(CCT) Other, 3000-7000k

Working Temperature(℃) -40, 60

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP67

Certification CCC, CE, CQC, EMC, LVD, PSE, SAA

Warranty(Year) 5

Place of Origin Zhejiang, China

Brand Name MCLED

Model Number ML015

bridgelux led chip high quality IP 67 LED street light

Apply to Roads, Highway, Highway Lighting, Bridge, Car Park, Garden, Park, Petrol Station, Sport Lighting, Square, Square Lighting.

Product Description

Model Item	ML015 - led street lights
LED Consumption	50W-200W
System Consumption	LED Power*1.1
Input Voltage	AC 100-265 V
Working Power Frequency Range	47-63HZ
Power Factor	>0.95
Total Harmonic Distortion	<20%
Working Environment	Temperature:-40℃~60℃; Humidity: 0~100%
Average Temperature in 24 hrs	≤35 °c
Surface Highest Temperature	≤60°c
Junction Temperature(TJ)	≤70°c
Lamp Luminous Efficacy(Lm/W)	≥110LM/W
LED Initial Flux (Lm)	LED POWER*110LM
Lamp Efficiency(%)	≥90%
Color Temperature	2500K~7000K
Color Rendering Index(CRI)	Ra›75
LED Life Span	>5000h
Protection Grade	IP67
Lens Light Transmittance	≥90%
Beam Angle	60°-160°
Net weight	9.5KG
Gross weight	11.5KG
Packing size	L105W41H25.5 CM
Note:Lens can be changed according to client's specific requirement.
