MCLED COB Bridgelux IP67 AC220V ATEX MF01-110W LED Explosion Proof lamp hazardous area lighting r Zone1 and Zone 2

Name: MCLED COB Bridgelux IP67 AC220V ATEX MF01-110W LED Explosion Proof lamp hazardous area lighting r Zone1 and Zone 2
Brand: MCLED
Availability: InStock

FOB Price

US$ 135 - 140 / Piece

1 Piece(Min. Order)

Port Ningbo
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	Bridgelux	Input Voltage(V)	AC85-265V
Lamp Power(W)	110	Lamp Luminous Flux(lm)	12100
Lamp Luminous Efficiency(lm/w)	110	Color Temperature(CCT)	Cool White
Working Temperature(℃)	-25, 45	Working Lifetime(Hour)	50000
IP Rating	IP67	Certification	CCC, CE, CQC, EMC, LVD, PSE, VDE
Emitting Color	White	Base Type	Other, mcled
Place of Origin	Zhejiang, China	Brand Name	MCLED
Model Number	MF01-110W

Product Description

MCLED COB Bridgelux IP67 AC220V ATEX MF01-110W LED Explosion Proof lamp hazardous area lighting r Zone1 and Zone 2

Product Description

Model Item	MF01-110W
LED Consumption	110W
System Consumption	Power*1.1
Input Voltage	85-265V
Working Power Frequency Range	50Hz/60Hz
Power Factor	>0.95
Total Harmonic Distortion	<20%
Working Environment	working temperature: -25℃-45℃ Woking Humidity:0-100%
Average Temperature in 24 hrs	<35°
Surface Highest Temperature	<60°
Junction Temperature(TJ)	<70°
Lamp Luminous Efficacy(Lm/W)	>110lm/w
LED Initial Flux (Lm)	LED consumption*110lm/w
Lamp Efficiency(%)	>90%
Color Temperature	2700-7000K
Color Rendering Index(CRI)	>70
LED Life Span	>50000
Protection Grade	IP67
Lens Light Transmittance	>90%
Beam Angle	60-120°
Net weight	6.3kgs
Gross weight	7.1kgs
Packing size	35.335.525cm
Note:Lens can be changed according to client's specific requirement.

Main products

Wide applications

FAQ

Q1: What is your Ex Grade?

A: It is ExII2GIIC T6 Gb

Q2. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q3:Which brand of LED chip MCLED use?

A: Amercial bridgelux

Q4: Can we have the sample for testing?

A: Of course the samples are possible. But we will charge for it. However, if the quantity is more than 250pcs, we will return the sample charge to you.

Q5: How long we can get the sample.

A: The lead time for samples ia usually 3 days.
