Help CenterU Shaped Quartz Tube for Sampler Thermocouple
Related Products
-
1'' Glass TubeUS$ 9 - 100MOQ: 50 Kilograms -
U Quartz Glass Transmission TubeUS$ 9 - 100MOQ: 50 Kilograms
-
U Bend Quartz Glass Tube(RE418-U)US$ 0.0076 - 0.2MOQ: 1 Piece
-
China Classical Thermocouples u Bend Quartz TubeUS$ 0.0076 - 0.2MOQ: 1 Piece
-
Special Best Sell Thermocouples u Bend Quartz TubeUS$ 0.0076 - 0.2MOQ: 1 Piece
Specifications
u shaped quartz tube sampler quartz tube with sligth tolearance by automatic machinebetter visual,best quality
U sharp quartz tube for sampler thermocouple
Feature of u shaped quartz tubes:
1.U Sharp Quartz Tube with tight size tolerance, slinky form and excellent feature.
2.Melting point at 1730 degree, mainly apply for Thermocouples, samplers and high temperature parts.
3.This products providing to Europe, America, the all and the one quality accord with international standard.
3*1.5*15mm
3*1.5*16mm
3*1.5*18mm
3*1.5*22mm
3*1.5*23mm
3*1.5*32mm
3*1.5*45mm
3*1.2*23mm
and etc
we can make as customer's drawings for different sizes. Please contact with us from more.
Parameter of u shaped quartz tubes:
| Model | RE418-U |
| Brand | Resucerial |
| Outer Diameter | 2.5,3mm |
| Purity | >99.95%(SiO2 content) |
| Wall Thickness | 0.50-1mm |
| Height | 15,16,18,22,23,26,42,45mm |
| Shape | U type |
| Softening Point | 1680℃ |
| Annealing Point | 1210℃ |
| Strain Point | 1120℃ |
| Density | 2.2g/cm |
| Hardness | 5.5-6.50Mohs' |
| Design Tensile Strength | 4.80x107N/m^2 |
| Design Compressive Strength | 1.10x109 N/m^2 |
| Cofficient Of Thermal Expansion(20-320℃) | 5.70x 10-7cm/cm.℃ |
| Thermal Conductivity(20℃) | 1.40W/m.℃ |
| Specific Heat(20℃) | 670J/Kg.℃ |
| Electrical Resistivity(350℃) | 7x107 ohm.cm |
| Dielectric Constant | 3.75 |
| Dielectric Strength | 5x 107 V/m |
| Typcial Application | Thermocouple sampler tube |
Chemical Composition | ||||||||||
AL | K | Na | Li | Ca | Mg | Cu | Mn | Pb | B | Ti |
20 | 3.5 | 3.5 | 1.0 | 2.0 | 0.5 | 0.3 | 0.5 | <0.01 | <0.2 | 2.0 |
Photos of u shaped quartz tubes:
Samples:
Application of u shaped quartz tubes:
1.Fused quartz glass tube available as continuous machine drawn and automatic controlled tubing.
2.This glass had the typical characteriastics of high purity, good spectral transmission, well controlled dimension and lower OH and so on.
3.It serves as the first choice of heat resistant material for halogen lamps, mercury lamps, metal halide lamps and other quartz lamps.
4.This glass can be supplied in the range of 3-450mm outside diameter, 0.6-20.0mm wall thickness and 10-4500mm length.
5.Exhaust tubes with good CPK are suitable for high-speed streamline production.
6.And further processing of trim cutting, fire polishing, bending and pinching and etc. can be done according to the requirement of customers.
7.OH-content can be controled within 20ppm15ppm10ppm5ppm2ppm according to the requirement of customers.
Samples:
Certification:
Production Process:
Packing:
Shipping:
Our Team:
Exhibition:
