Good quality hot sale ir quartz emitter

Specifications

ir quartz emitter
1.Rapid heat-up
2.Halogen type, rapid response
3.Short wave infrared radiates

Good quality hot sale ir quartz emitter



Feature of ir quartz emitter:

1. Fast Response

2. Rapid heat-up

3. Rapid cool down

4. Ideal for fast cycling machines

5. Highly reflective aluminized internal surface

6. High radiant efficiency

7. Low convection losses

8.Five Standard Sizes: 122 x 62 x 25mm, 122 x 120 x 25mm, 248 x 62 x 25mm, 248 x 120 x 25mm,306 x 306 x 25mm

Also we can make as buyer’s requirements. please send your drawings or sketch to confirm

9. Large choice of power ratings available

10. Volts: Heater can be manufactured to suit most supply voltages



Parameter of ir quartz emitter:

Model	RE926-Q
Brand	Resucerial
Applications	heating, drying
Radiation Wavelengths	1-25um
Certificate	CE
Life Time	5000h
Heating Resistance Wire	Ni-Cr-Al Alloy wire
Envelope	304/Al/Fe
Shape	flat
Color	white
Voltage	12v,24v,36v,75v,110v,120v,220v,230v,240v,380v,400v,415v
Watts	50-3000w
Sizes(Mm)	245x65,240x60,120x60,120x120



Photos of ir quartz emitter:













Samples:



Application of ir quartz emitter:

1.Quartz emitters provide medium wavelength radiation and can be the most preferred source of heat when rapid heater response is needed.

2.The heaters are comprised of a series of quartz tubes running parallel to each other within a highly reflective aluminized steel housing.

3.Each tube contains a coiled resistance wire available in a variety of wattages and voltages.

 4.Watt densities up to 30 w/sq. inch (4.65 w/sq. cm) are available.

5.The large variety of sizes, shapes, and watt densities allows quartz emitters to be highly useful in zoning arrangements such as plastic thermoforming sheet-fed applications where complex heating patterns are needed, high-speed roll-fed processes, and machines requiring precise zone control because they are small in size, and can easily be put in larger panels.

Mainly apply to car lacquer oven, glass machining, plastic, powder spread, typographic, paper making, textile, environmentalist, semiconductor, water treatment, food processing, analytical, pharmacy industry field
