Solar Products-Solar Water Heater

Solar Products-Solar Water Heater photo-1
US$ 100 - 899 MOQ: 10 Sets
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Unpressurized
Circulation Type:
Direct / Open Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Type Evacuated Tube
Pressure Unpressurized
Circulation Type Direct / Open Loop (Active)
Heating System Thermosyphon (Passive)
Connection Type Direct-Plug
Installation Freestanding
Housing Material Stainless Steel
Capacity 300
Place of Origin Zhejiang, China
Brand Name Yueneng/OEM
Model Number GX-460-58/2100

Specifications

Solar hot water heater /OEM
1)10years warranty and best after service
2)various model
3)fast delivery.

Solar hot water heater specification:
1. Inner tank: 0.4mm-0.6mm thickness SUS 304-2B Stainless steel
2. Tank diameter: 470mm/480mm outer tank, 360mm/370mm inner tank
3. Vacuum tube: QB-AL-N/AL-47-1500mm/58-1800mm
4. Outer tank: 0.31mm-0.4mm thickness Wiredrawing Metal Plate/Fluorin Carbon Plate/Color Steel
5. Frame: 1.2mm thickness Aluminum Alloy/1.5mm thickness Galvanized Steel
6. The material of insulation: 55-60mm thickness Polyurethane
7. The reflector: Stainless steel /Aluminum plate
8. Working efficiency: >95%
9. Heat Preservation time: 72-96hours
10. Hail resistance: 25mm
11. Inlet/oulet size: 1/2'', 3/4''
12. Tank capacity: 100L/110L/115L/135L/150L/165L/200L/250L/285L/300L
13. Air vent: 100% copper vent


Solar hot water warranty:
1.5 years manufacturer's warranty against deffects in material and workmanship.
2.10 years for vacuum tube





 More details:

    Model                 Tank                                Vacuum Tube Absorption
Area(m 2 )
Capacity Diameter Diameter Length Tube quantity
OSNP-47-15 100L 420mm 47mm 1500mm 15 0.45
OSNP-47-18 110L 420mm 47mm 1500mm 18 0.51
OSNP-47-20 125L 420mm 47mm 1500mm 20 0.56
OSNP-47-24 150L 420mm 47mm 1500mm 24 0.62
OSNP-47-30 180L 420mm 47mm 1500mm 30 0.77
OSNP-47-32 200L 420mm 47mm 1500mm 32 0.85
OSNP-58-15 135L 470mm 58mm 1800mm 15 0.59
OSNP-58-18 150L 470mm 58mm 1800mm 18 0.69
OSNP-58-20 165L 470mm 58mm 1800mm 20 0.75
OSNP-58-24 200L 470mm 58mm 1800mm 24 0.89
OSNP-58-30 250L 470mm 58mm 1800mm 30 1.07
OSNP-58-32 285L 470mm 58mm 1800mm 32 1.11



 Picture display:

Solar products-Solar water heater
