Ultrasonic Calorimeter Meters

US$ 200 - 350 MOQ: 1 Set

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

MEC

Model Number:

TUF-2000P

Liaoning Mec Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

china

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name MEC

Model Number TUF-2000P

ultrasonic Calorimeter/heat meter

Items	Specifications
Main unit	2 line x 20 character LCD with backlight Working temperature: -25--60°C
	Mini thermal printer with 24 line character output
	4x4+2 pushbutton keypad
	RS-485 interface for networking
Ultrasonic Transducer options	TS-1: small size transducer (magnetic) for pipe size: DN15-100mm, liquid temperature ≤110°C
	TM-1:medium size transducer (magnetic) for pipe size:DN50-1000mm, liquid temperature ≤110°C
	TL-1: Large size transducer (magnetic) for pipe size: DN300-6000mm, liquid temperature ≤110°C
Temperature Transducer	Three wire pt100 platinic resistance, measuring range :-50 -----180°C measuring accuracy:100°C, 0.8°C , the temperature difference ≤0.1°C
Liquid types	Water, sea water, industrial sewage, acid and alkali liquid, various oils etc. liquid which can transmit sound wave.
Flow velocity range	0- ±30m/s
Accuracy	Better than ±1%
Power Supply	Built-in rechargeable Ni-MH battery (for 20 hours operation) or AC 220V
Power Consumption	1.5W
Charging	Intelligent charging with AC 220V; After charging sufficiently, it automatically stop and display green light
Weight	Net weight: 2.5kg (main unit)
