10kv 24kv Polymer Pin Insulator
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
GEM
Type:
Insulator
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Liaoning, China
Brand Name
GEM
Type
Insulator
Material
Composite Polymer
Application
High Voltage
Rated Voltage
10 or 24
Specifications
Be applied whole injection technique, the combination of hardware fittings and glassfiber core are employed compressiontechniqueParameters:
| No. | Type Code | Rated Voltage (kV) | Rated Mechanical Tensile Strength kN | Structure Height H (mm) | Insulation Distance H (mm) | Min. Nominal Creepage Distance (mm) | Lighting Impulse Withstand Voltage, peak ≥ kV | Power Frequency Withstand Voltage, 1 min ≥ kV | Weiht (kg) |
Dwg. No. |
| 1 | FPW-10/4 | 10 | 4 | 230±5 | 150 | 365 | 90 | 40 | 1.2 | 11 |
| 2 | FPW-24/5 | 24 | 5 | 252±5 | 218 | 640 | 175 | 70 | 2 | 12 |
