We are supplying DMU/EMU with different specifications, inclduing single deck and double deck.
Main technical parameters:
1 |
Vehicle formation |
Mc+T+Mc |
2 |
Track gauge |
1435mm |
3 |
Number of cabs per DMU |
2 |
4 |
Material of carbody |
Stainless steel |
5 |
Tractive power type |
hydro-mechanical |
6 |
Maximum axle load |
13t |
7 |
Total weight of one unit |
52t |
8 |
Number of door per car side |
3 |
9 |
Horizontal curve radius (min) |
90 m |
10 |
Vertical curve radius( min) |
500 m |
|
Car capacity |
200 passengers (6 persons/m²) |
11 |
Maximum speed |
120 km/h |
12 |
Average acceleration rate until 40km/h(min) |
0.4 m/s2 |
13 |
Height of car body Motor car: Trailer car: |
4000mm 4000mm |
14 |
Height of floor above rail top: Motor car: Trailer car |
1100mm 1100mm |
15 |
Height of coupler center line above rail top(Mc): |
660mm |
16 |
Height of coupler center line above rail top(T): |
660mm |
