Home > Electrical & Electronics > Power Supply & Distribution > Power Distribution Cabinet & Box > 110KV Composite Rod Post Insulators
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
GEM
Model Number:
GEM
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shanghai, China
Brand Name
GEM
Model Number
GEM
Specifications
110KV Composite rod post insulators applicable to substation have good characteristics of water hydrophobe aging resistance.Product Description
110KV Composite rod post insulators
Rod post size and technical insulators applicable to substation have good characteristics of water hydrophobe aging resistance, tracking resistance and corrosive. They have big helectrical performance:silicone rubber sheds are good hydrophobe and have water floating capacity heavy pollution resistance, canprevent flash over due to pollution. it can work on the severely polluted sites without special clearing. the top and bottom installation sizes can be designed same to those of porcelain post insulators.
| Rod post size and technical insulators | |||||||||
| Type | height (mm) | Min. electric arc distance (mm) | Min norminal creepage distance (mm) | Rated mechnical failling load | Power frequency withstand voltage | Full wave lightning impulse withstand voltage (peak value) (KV) | Highest operating voltage of equipment(KV) | ||
| Bent (KN) | Distortion(KN) | 1 min Wet (KV) | 1 min Dry (KV) | ||||||
| FZSW-12/2.5 | 225 | 129 | 300 | 5 | 0.6 | 30 | 42 | 75 | 12 |
| FZSW-40.5/6 | 445 | 345 | 1015 | 6 | 1.5 | 80 | 100 | 185 | 40.5 |
| FZSW-72.5/6 | 770 | 635 | 1830 | 6 | 2 | 140 | 165 | 325 | 72.5 |
| FZSW-126/10 | 1220 | 1060 | 3180 | 10 | 4 | 185 | 265 | 450 | 126 |
