Composite Rod Post Insulators
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
GEM
Model Number:
GEM
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Composite Cross- Arm Used Insulators Are Applicable to Urban Power Network Reconstruction whNegotiableMOQ: 100 Pieces -
12KV 40.5KV 72.5KV 126KV Composite Rod Post InsulatorsNegotiableMOQ: 100 Pieces
-
12KV-36KV Polymer InsulatorNegotiableMOQ: 100 Pieces
-
10KV-500KV Polymer Suspension InsulatorNegotiableMOQ: 500 Pieces
-
10KV-100KV Composite Cross- Arm Used InsulatorsNegotiableMOQ: 100 Pieces
Place of Origin
Shanghai, China
Brand Name
GEM
Model Number
GEM
Specifications
Composite rod post insulators applicable to substation have good characteristics of water hydrophobe aging resistance and so on.Product Description
Rod post size and technical insulators applicable to substation have good characteristics of water hydrophobe aging resistance, tracking resistance and corrosive. They have big helectrical performance:silicone rubber sheds are good hydrophobe and have water floating capacity heavy pollution resistance, canprevent flash over due to pollution. it can work on the severely polluted sites without special clearing. the top and bottom installation sizes can be designed same to those of porcelain post insulators.
| Rod post size and technical insulators | |||||||||
| Type | height (mm) | Min. electric arc distance (mm) | Min norminal creepage distance (mm) | Rated mechnical failling load | Power frequency withstand voltage | Full wave lightning impulse withstand voltage (peak value) (KV) | Highest operating voltage of equipment(KV) | ||
| Bent (KN) | Distortion(KN) | 1 min Wet (KV) | 1 min Dry (KV) | ||||||
| FZSW-12/2.5 | 225 | 129 | 300 | 5 | 0.6 | 30 | 42 | 75 | 12 |
| FZSW-40.5/6 | 445 | 345 | 1015 | 6 | 1.5 | 80 | 100 | 185 | 40.5 |
| FZSW-72.5/6 | 770 | 635 | 1830 | 6 | 2 | 140 | 165 | 325 | 72.5 |
| FZSW-126/10 | 1220 | 1060 | 3180 | 10 | 4 | 185 | 265 | 450 | 126 |
