Help CenterNew Fast Speed Computerized Chain Multi-needle Quilting Machine HY-W-SJ
Related Products
-
Computerized Lock Stitch Multi-Needle Quilting Machine HY-128-3ANegotiableMOQ: 1 Unit -
Computerized Chain Stitch Multi-functional Quilting MachineNegotiableMOQ: 1 Set
-
3 Computerized Lock Stitch Multi-needle Quilting MachineNegotiableMOQ: 1 Set
-
2012 Material Rolling DeviceNegotiableMOQ: 1 Set
-
Hiigh Speed Computerized Chain Stitch Multi-needle Quilting MachineUS$ 58,000 - 60,000MOQ: 5 Sets
Purpose:It is widely used for quilting high-quality mattresses, quilt covers, and household ornaments. Different patterns are available.
Parameter(Unit:mm):
Dimension(L×W×H) :4720×1670×2050
Quilting width:2450
Space between needle rows: 50.8,76.2,127(5”)
Space between needle rows: 76.2,76.2,152.4(6”)
Space between needles:25.4
X-axis movement displacement:410
Thickness of quilting≤80(for all patterns)
Stitch length:3-8
Speed of operation:60~300(m/hour)
Model of needle:24/180 23/160 22/140 21/130
Quilting speed:1200(RPM/MIN)
Total power required:7KW
Voltage :380V/50HZ 220V/60HZ
Gross weight:5000kg
Detail Information:
• Optimized the mechanical structure make the higher speed and more production.
• The practical patented product “moving needle plate” will make the quilting patterns more elegant.
• More tight thread stitches make the quilting pattern have a stronger third dimension.
• Needle bar and press plate are controlled by a double- swinging device without cam avoiding lubrication and dirtying of material
• Multi-span and independent patterns(360°and 180°patterns are available)
• Automatic stop motion control in case the top thread or the bottom thread breaks,automatic needle-lifting and CNC speed adjustment
• CE Certificate
• No need to adjust the press plate' s position when the thickness of quilting material varies
• Outstanding features such as high rigidity, high running speed, low vibration and noise
• CNC precision control system
• Easy preparation of CAD drawings extremely precise
• Strong functions of pattern-combining and multi-span quilting to enable you to quilt different patterns in each row in the mattresses of different sizes
• Fault detection function for ease of determining the running state of the machine at any given time
