3 Computerized Lock Stitch Multi-needle Quilting Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HENGYE (HY)
Model Number:
HY-94-3,HY-98-3,HY-118-3,HY-128-3
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2012 Material Rolling DeviceNegotiableMOQ: 1 Set -
Hiigh Speed Computerized Chain Stitch Multi-needle Quilting MachineUS$ 58,000 - 60,000MOQ: 5 Sets
-
Computerized Chain Stitch Multi-needle Quilting MachineUS$ 47,000 - 48,000MOQ: 5 Sets
-
Computerized Chain Stitch Multi-function Quilting MachineNegotiableMOQ: 1 Set
-
Material Roller Machine HY-JB-1/ HY-JB-2NegotiableMOQ: 1
Place of Origin
Guangdong, China
Brand Name
HENGYE (HY)
Model Number
HY-94-3,HY-98-3,HY-118-3,HY-128-3
Specifications
Purpose: It is widely used for quilting high-quality bedding covers, quilt covers, garments, seat-covers and household ornamentsPurpose : It is widely used for quilting high-quality mattresses , quilt covers , and household ornaments . Different patterns are available
- Multi-span independent pattern (360°and 180°patterns are available ).
- Advanced and practical top thread-break detection techniques .
- Automatic needle-lifting and computerized speed adjustment .
- New generation of CNC system , advanced machine structure , high precision quilting , dispense with too much parameter adjustment or pattern modification during quilting .
- CAD drawing method to ensure the precision of pattern and facilitate the operation .
- Different patterns in each line can be quilted on 3.2m fabric and patterns can strongly combine.
- Able to quilt simple embroidery patterns.
-
Operation detecting and indicating for checking as clear as possible .
Parameter Unit ( mm )
| HY-94-2A | HY-94-3A | HY-128-3A | |
| (NEW STRUCTURE) | (NEW STRUCTURE) | (NEW STRUCTURE) | |
| Dimension(L×W×H) | 4500×1120×1750 | 4500×1160×1750 | 4500×1160×1800 |
| Quantity of needle bar | 2 | 3 | 3 |
| Quilting width | 2450 | 2450 | 3300 |
| Space between needle rows | 76.2 | 76.2,152.4 | 76.2,152.4 |
| Space between needles | 25.4 | 25.4 | 25.4 |
| X-axis movement displacement | 305 | 305 | 305 |
| Thickness of quilting | ≤25 | ≤25 | ≤25 |
| Stitch length | 2~5 | 2~5 | 2~5 |
| Speed of production(m/h) | 20~110 | 20~110 | 20~90 |
| Model of needle | 16#, 19# | 16#, 19# | 16#, 19# |
| Speed of main shaft(RPM) | 550~600 | 550~600 | 550~650 |
| Total power required(KW) | 3.5 | 3.5 | 4.5 |
| Voltage | 380V/50HZ, 220V/60HZ | 380V/50HZ, 220V/60HZ | 380V/50HZ, 220V/60HZ |
| Gross weight | 2300kg | 2800kg | 4200kg |
Note:When you order,please make sure the type of the bobbin,10#or7#
