CMP type T3CDS cable gland
Material: Brass, Brass Nickel Plated & Stainless Steel
Accessories include: Locknut, Earth tag, PVC Shroud and Nylon Washer.
CMP Triton CDS Type T3CDS Triple Certified Flameproof (Type 'd'), Increased Safety (Type 'e') and Restricted Breathing (Type ‘nR’)
indoor and outdoor cable gland for use in Zone 1, Zone 2, Zone 21 and Zone 22 Hazardous Areas with all types of armoured cable
providing a Flameproof seal on the cable inner bedding and an environmental seal on the cable outer sheath. This product utilises a
unique Compensating Displacement Seal (CDS) system which provides full compatibility with Restricted Breathing equipment. The
cable gland provides mechanical cable retention and electrical continuity via armour wire termination. A reversible armour cone and
AnyWay universal clamping ring arrangement allows the cable to be easily disconnected from the equipment, for maintenance and
change out etc., and re-connected with the same consummate ease. This feature also facilitates remote make off procedures when
the termination is to be conducted in confined spaces or in areas of restricted access. Separate tightening actions for the inner
Compensating Displacement Seal (CDS) system and the armour termination affords maximum control over the pressure applied to
the cable inner bedding. The CMP Triton CDS Cable Gland is suitable for use with all forms of equipment protection permitted in
Zone 1, Zone 2 , Zone 21 & Zone 22 provided always that the prevailing code of practice for selection and installation is observed,
e.g. IEC 60079-14.
