PU fibre glass inuslation pipe
- 1000 Meter / Meters per Month
- shenzhen
- Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
- 3240 Epoxy Board, High-quality Insulation Material, Flexible Customization, Widely Applicable 3240 Epoxy Sheet
- Chinese Factory Electrical Insulation Brown 3025 Phenolic Bakelite Resin Cotton Cloth Fabric Laminate Board Sheet Phenolic Board
- 4x8 fiberglass sheets g10 epoxy glass fiber board g10 material
- Factory Price Bakelite Decorative HPL Press plates bakelite sheet
- Black G10 Sheet - High Quality Carbon Fiber G10 FR4 Sheets - Precision-made PCB Materials
Product Details
Place of Origin: | Guangdong, China | Brand Name: | sunbow | Model Number: | SB-PU |
Type: | Insulation Sleeving | Material: | Other, Fiberglass+PU | Application: | Low Voltage |
Rated Voltage: | 2.5kv & 4kv | Tensile Strength: | >4Mpa |
Product Description
PU coated fiberglass braided insulation sleeving Detailed Product Description:
1.Non-alkali fiberglass braided coated with PU resin.
2.Working temperature: -30 to +155 C.
3.UL standard.RoHS tested.
CHARACTERISTICS:
Temperature class: CLASS F
Working temperature: From - 30 °C to + 155 °C. Peak to + 185°C (a few hours)
Dielectric strength: 3 to 10 kV
Halogen free
Flammability: Combustible but subsistence of the fiberglass
Good mechanical resistance:Resistance to transformer oils according to UTEC 93641
Good compatibility with class F impregnation varnishes
Good behavior with soldering iron
Good behavior with liquid combustibles, no decomposition
Watertight
USAGE: Electromechanical industry (motors, transformers, generator...), fit for all class F insulation.
Dimensions:
Inner diameter | Tolerance inner diameter | Wall thickness minimum | Wall thickness maximum |
0.5mm | ±0.15mm | 0.35mm | 0.65mm |
0.8mm | ±0.20mm | 0.35mm | 0.65mm |
1.0mm | ±0.20mm | 0.35mm | 0.65mm |
1.5mm | ±0.20mm | 0.35mm | 0.65mm |
2.0mm | ±0.20mm | 0.35mm | 0.65mm |
2.5mm | ±0.20mm | 0.35mm | 0.65mm |
3.0mm | ±0.25mm | 0.35mm | 0.65mm |
3.5mm | ±0.25mm | 0.35mm | 0.65mm |
4.0mm | ±0.25mm | 0.35mm | 0.65mm |
4.5mm | ±0.25mm | 0.35mm | 0.65mm |
5.0mm | ±0.25mm | 0.35mm | 0.65mm |
6.0mm | ±0.25mm | 0.35mm | 0.65mm |
7.0mm | ±0.25mm | 0.35mm | 0.65mm |
8.0mm | ±0.30mm | 0.50mm | 0.90mm |
9.0mm | ±0.30mm | 0.50mm | 0.90mm |
10.0mm | ±0.30mm | 0.50mm | 0.90mm |
12.0mm | ±0.30mm | 0.50mm | 0.90mm |
14.0mm | ±0.50mm | 0.50mm | 1.00mm |
16.0mm | ±0.50mm | 0.50mm | 1.00mm |
18.0mm | ±0.50mm | 0.50mm | 1.00mm |
20.0mm | ±0.50mm | 0.50mm | 1.00mm |
22.0mm | ±0.60mm | 0.50mm | 1.50mm |
25.0mm | ±0.60mm | 0.50mm | 1.50mm |
30.0mm | ±0.60mm | 1.00mm | 2.00mm |
