SUNBOW High Temperature Resistant Fire-resistance 12MM Silicone Rubber Glassfiber Sleeve (Video: /en/about-100.html)
PRODUCT DESCRIPTION
SUNBOW High Temperature Resistant Fire-resistance 12MM Silicone Rubber Glassfiber Sleeve is made of extruded silicone rubber, reinforced with non-alkaline fiberglass braided, and then coated with silicone resin and treated in high temperature.
APPLICATION
SUNBOW High Temperature Resistant Fire-resistance 12MM Silicone Rubber Glassfiber Sleeve possesses excellent heat and cold resistance performances. It can be continuously operated at 200ºC high temperature. In extreme conditions it can resist 250ºC for a short time. Besides, excellent electrical and mechanical strength properties make it very suitable for a wide range of application. It is popularly used in motors, home electrical appliances, lights, electric heaters etc.
SPECIFICATION
Item |
Performance |
Note |
|
Dielectric Breakdown Voltage KV AC |
≥7.0 |
In Air |
≥6.0 |
In Water |
|
≥5.0 |
In 2% Salt Water |
|
Thermal Endurance |
No Indication of Crack |
250ºC *1 Hrs |
Fire Resistance |
VW-1 |
UL 1441 |
DIMENSION
Inner Diameter (mm) |
Wall Thickness (mm) |
Standard Package (m/roll) |
|
Nominal |
Tolerance |
||
1.0-2.5 |
+0.20, -0.00 |
0.60±0.05 |
200 |
3.0-5.0 |
+0.30, -0.00 |
0.70±0.05 |
100 |
6.0-7.0 |
+0.35, -0.00 |
0.75±0.05 |
100 |
8.0-9.0 |
+0.40, -0.00 |
0.80±0.05 |
100 |
10.0-12.0 |
+0.50,-0.00 |
0.90±0.05 |
50 |
14.0-25.0 |
+0.65,-0.00 |
1.30±0.05 |
25 |
FAQ
Q1. You are a factory or trading company?
We are a factory and we can provide best price and high quality products for you.
Q2. Can you accept sample orders?
Yes, we can accept sample orders and we can also provide free samples for your test if necessary.
Q3. What is your MOQ?
Normally, 1000m per size.
Q4. What are your payment terms?
T/T 100% or West Union
Q5. How can I get my order? How can I know you sent the goods?
We will send the goods by UPS, DHL, FedEx or sea shipment. After we sent the goods , we will give you the tracking number or other relative files for your check.
Q6. How about your quality?
Try a small order, and then you can judge.
Q7. Have you passed any certificates?
Yes. We are an ISO9001:2008 quality management system certificated manufacturer. Our products have passed UL, ROHS, REACH certifications. If necessary, we can send you relative files.
Q8. Are there any advantages to choose your products?
1) ISO 9001 : 2008 TS 16949 standard factory manufacturer
2) high-tech enterprise in China
3) with 12-year manufacturing experience
4) factory direct sales
5) best price high quality product
6) quick delivery time
7) quick response for feedback
8) few complaints from customers
9) more competitive price for VIP customers
10) convenient situation near to seaport
