HF-I/II AXIAL FAN
Compared with the common axial fan,HF-I type axial fan and HF-II multi-blade adjustable axial fan have a larger air flow,a higher pressure and other features,which is widely used for ventilation in the mining factories,civil building and etc.
In addition,the profile of HF-II is shaped with chromium blade and the angle adjustment can be arbitrary.With CASA design,the hub and the blades are casting from high quality alumium alloy in precision,which allows high intensity and a certain ability to decay.
HF-I/HF-II are the suitable for places that do not contain flammable,explosive and corrosive gased with the temperature no higher than 80 centigrade degree.
Model No. |
Power(KW) |
Rotation(r/min) |
Volume(m3/h) |
Pressure(Pa) |
Noise dB(A) |
HF-I4A |
0.75 |
1400 |
4500 |
65 |
≤70 |
|
0.9 |
2800 |
9000 |
282 |
≤84 |
HF-I-5A |
1.1 |
1400 |
5500 |
99 |
≤76 |
|
1.5 |
2800 |
10700 |
197 |
≤85 |
HF-I-6A |
2.2 |
1420 |
9500 |
162 |
≤87 |
|
3 |
2900 |
18000 |
170 |
≤86 |
HF-II-15' |
0.75 |
1400 |
4000 |
73 |
≤70 |
|
1.5 |
2800 |
8000 |
323 |
≤87 |
HF-II-19' |
1.5 |
1400 |
8713 |
177 |
≤80 |
|
3 |
2900 |
14000 |
318 |
≤86 |
HF-II-24' |
2.2 |
1420 |
16000 |
182 |
≤87 |
|
4 |
1450 |
19000 |
300 |
≤89 |
....
