Help Center8" White Mini Pro Audio,professional Speaker,loudspeaker
Related Products
1. The Blakline AQ8 is a versatile, 2-way passive system, designed to provide exceptional club sound reinforcement and stage monitoring from a very compact enclosure.
2. It features a powerful 8″(200mm) low frequency driver and a 1″(25mm) HF compression driver mounted on a constant directivity 90°×50° horn.
3. Depending on the application, the HF horn can be rotated to allow the multi-angle enclosure to be used in either its vertical or horizontal orientation.
AQ8 Speaker features:
♣ A 8" 2-way passive stage speaker, 200-400watts, with one 8" LF and one 1.4" HF drivers.
♣ Strong penetrating, high fidelity and low distortion, clear, pure and natural tone quality.
♣ With multilayer plywood, environmental textured black painting, newest humanzied design, simple and esay for rigging.
♣ Widely used in AV application system, small meeting room, stage, theater, clubs, discos ect.
AQ8 speaker specifications:
TYPE |
Compact, two-way passive |
FREQUENCY |
68Hz-19kHz±3dB |
RESPONSE(1) |
-10dB@56Hz |
DRIVERS |
8″(200mm)/2″(50mm)voice coil LF driver |
Voice coil HF driver size 1.4″34mm) | |
RATED POWER(2) |
200W AES, 400W peak |
SENSITIVITY(3) |
95dB |
MAXIMUM SPL(4) |
117dB peak |
NOMINAL IMPEDANCE |
8 ohms |
CONNECTORS |
2×Neutrik NL4 |
|
FITTINGS
|
8×M8,4×M8 threaded inserts |
1×mounting pole socket | |
DIMENSIONS |
(W)350×(H)500×(D)317mm |
WEIGHT |
16kg |
♦ Our factory supports Alibaba Trade Assurance, 100% product quality protection.
♦ OEM or ODM orders are warmly welcomed, we could produce varies speakers according to your drawings.
♦ Offer 1year free warranty, except the man-made damaged.
♦ All the products will be tested and inspected before the delivery.
AQ8 Speaker box design:
AQ8 speaker driver configurations:
