Help CenterRF20TT+ Neodymium 10inch Audio
Related Products
RF20TT+ pro speaker descriptions:
1. RF20TT+ is a versatile, 2-way passive system, designed to provide exceptional club sound reinforcement and stage monitoring from a very compact enclosure.
2. It features a powerful 10″(250mm) low frequency driver and a 1.4″(34mm) HF compression driver mounted on a constant directivity 80°×60° horn.
3. Depending on the application, the HF horn can be rotated to allow the multi-angle enclosure to be used in either its vertical or horizontal orientation.
RF20TT+ pro speaker features:
♣ A 10" 2-way passive stage speaker, 350-700watts, with one 10" Neodymium LF and one 1.4" Neodymium HF drivers.
♣ Strong penetrating, high fidelity and low distortion, clear, pure and natural tone quality.
♣ With multilayer plywood, environmental jbl black painting, newest humanzied design, simple and esay for rigging.
♣ Widely used in AV application system, meeting room, stage, theater, clubs, discos ect.
RF20TT+ pro speaker specifications:
RF20TT+ | |
TYPE |
Compact, two-way passive |
FREQUENCY |
65Hz-20kHz±3dB |
RESPONSE(1) |
-10dB@60Hz |
DRIVERS |
10″(250mm)/2.5″(63mm)voice coil LF driver |
|
Voice coil HF driver size 1.4″(34mm) |
RATED POWER(2) |
350W AES, 700W peak |
SENSITIVITY(3) |
97dB |
MAXIMUM SPL(4) |
119Db continuous, 123dB peak |
NOMINAL IMPEDANCE |
8 ohms |
DISPERSION (-6dB) |
126dB peakA |
CONNECTORS |
3×Neutrik NL4 |
FITTINGS |
8×M8,4×M8 threaded inserts |
|
1×mounting pole socket |
DIMENSIONS |
(w)300×(D)300 ×(H)480 mm |
WEIGHT |
15 kg |
♦ Our factory supports Alibaba Trade Assurance, 100% product quality protection.
♦ OEM or ODM orders are warmly welcomed, we could produce varies speakers according to your drawings.
♦ Offer 1year free warranty, except the man-made damaged.
♦ All the products will be tested and inspected before the delivery.
RF20TT+ pro speaker configurations:
